Help CenterShanghai Automatic Single Line Red Wine Filling Line
Related Products
-
Automatic Single Line Grape Wine Filling LineUS$ 9,999 - 9,999MOQ: 1 Set -
Leadworld Automatic Single Line White Wine Filling LineUS$ 9,999 - 9,999MOQ: 1 Set
-
Automatic Single Line White Spirits Filling LineUS$ 9,999 - 9,999MOQ: 1 Set
-
Automatic Single Line Wine Fruit Wine Filling LineUS$ 9,999 - 9,999MOQ: 1 Set
-
Automatic Single Line Cooking Wine Filling LineUS$ 9,999 - 9,999MOQ: 1 Set
1.The filling machine is used to bottle pure water and mineral water and it is also suiable for liquid material.
2.Pulp filling machine is integrated with washing, filling and capping in one machine. It takes bottle handling technology, which makes changing different size bottle more easily. It can do the bottles from size 200ml to 2000ml. And little spares are need when changing bottles. We suggest users to take same specification bottles, especially the same bottle neck.
3.Our mono-bloc uses high quality stainless steel 304, which makes sure the quality of the producs.
4.The washing we take reversing bottle methods. It has so many washing heads which will spray the inside of the bottle after the bottle is reversed. After washing there will approximate 2 seconds dropping water.
5.Capping we use magnetic capper. And capping power can be adjusted. We equip the machine with "No-bottle, No-Cap" system. If there is no bottle, the caps feeding will be stopped. The capper feeder is stand beside the mono-bloc, which is parallel to the machine.
| Model: | LW-XGF12-12-5 | LW-XGF16-12-6 | LW-XGF18-18-6 | LW-XGF24-24-8 | LW-XGF32-32-10 |
| capacity (500ml based) | 3000BPH | 4000BPH | 6000BPH | 10000BPH | 12000BPH |
| Suitable bottle : | Round bottle or square bottle | ||||
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | ||||
| Suitable cap specification | PE screw cap | ||||
| filling precision: | ≤±5mm | ||||
| filling pressure:(Mpa) | ≤0.4Mpa | ||||
| Machine power | 4.4 | 5.2 | 6.2 | 6.8 | 8 |
| Machine size:(mm) | 2150*1650*2250 | 2400*1965*2250 | 2680*2200*2250 | 3000*2200*2250 | 3200*2250*2500 |
| weight: (kg) | 2800 | 3500 | 4500 | 5500 | 6500 |
