Specifications
Bottle Sorting Round Table1. High speed
2. Suitable for various types of caps
3. Easy to operate
Product Description
LW-ACT200 Auto Capping Machine includes automatically cap sorting, cap feeding and capping function. The bottles are entering in line, and then continuous capping, high efficiency. It is widely used in industries of cosmetics, food, beverage, medicine, biotechnology, health care, personal care chemical etc. It is suitable for all kinds of bottles with screwed caps.
1. Cappers are designed to handle most bottle types, because both the chuck height and the torque can be adjusted, a single machine can be used to tighten a variety of bottle caps of different sizes. The cappers have a simple and subtle design and can be installed on conveyors and working tables easily. It’s an ideal choice that be used on working line or single production.
2. The capper can secure the caps onto the bottles automatically. The machine can effectively reduce operator fatigue and keep the tightening torque consistent.
3. Include varying sizes of capping head, inner tuck and stainless steel worktables. We can make the machine according to clients’ requirements.
Technical Parameters
Diameter of bottle: 30-120mm
Height of bottle: 50-350mm
Capacity: 60-200 bottles/min
Power: 1.2kw
Frame material: stainless steel 304
Special specification can be customized
Component list of capping machine for clients' reference
No. | Name | Brand |
1 | Frequency converter | Danfoss (Denmark) |
2 | Motor | Chengbang (Taiwan) |
3 | Contactor | Moeller (Germany) |
4 | Relay | Schneider (France) |
5 | Linear Bearing | Igus (Germany) |
6 | Proximity switch | Omron (Japan) |
7 | Bearing | Chinese brand |
8 | Terminal block | Weidmuller(Germany) |
9 | Button | Chint |
10 | Speedcontroller | TWT(Taiwan) |
11 | Twist cap round | Silica gel round |
12 | Stainless steel 304 screw, chain and chain wheel(Chinese brand) |
|
13 | Wire | Qifan (famous Chinese brand ) |
14 | Synchronous belt | Kunshan GPB |
15 | Solenoidvalve | Airtac (Taiwan) |
16 | Cylinder | Airtac (Taiwan) |
17 | FRL | Airtac (Taiwan) |
18 | Optoelectronic switch | Omron(Japan) |
