DONGFENG KINGRUN 4*2 Flatbed Wrecker Truck 5 Ton
Flatbed Wrecker Truck , is also called as towing truck, trailer, or towing equipment truck,is mainly used for safety salvage of vehicles subject to city road, suburb way, highway,airport and bridge road. It is suitable for medium and smallsized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind. It is made of the chassis, hoisting equipment, lifting and towing equipment, hydraulic system, electric control system, truck body and the tool boxes. Road wrecker can hoist, lift, tow and be with
other special functions, mainly used in highway and city road obstacle handling.
Classification of Wrecker Truck as the following:
1.One-drive-two flatbed wrecker;
2.Towing & hoisting connected wrecker truck
3.Towing & hoisting separated wrecker truck
4.Wrecker truck with platform Functional wrecker truck
5.Wrecker truck with 360°rotating crane
6.Hydraulic automatic clamping wrecker truck
Main Parameter of DONGFENG KINGRUN 4*2 Flatbed Wrecker Truck 5 Ton
Whole truck Main Technical Parameter | |||
Product Name |
DONGFENG Flatbed Wrecker Truck |
Overall Dimension(L*W*H)(mm) |
9130×2420×2920 |
Wheelbase(mm) |
4700 |
Flatbed dimension(L*W)(mm) |
6200*2300 |
Front/ rear suspension(mm) |
1430/3000 |
Axle number |
2 |
Payload weight (kg) |
5400 |
Curb weight(kg) |
7340 |
Approach/ departure angle (° ) |
20/13 |
Max Speed (km/h) |
90 |
Cab capacity |
3 |
Cab Type |
Single row, front turn |
Chassis Technical Parameter | |||
Chassis Model: |
DFL1120B |
Chassis manufacturer: |
DONGFENG Motor Co., Ltd |
Gear Box |
DONGFENG 6 shift |
Transmission type: |
Manual |
Brake System |
Air brake |
Number of Tire |
6 with a spare |
Steering Type |
LHD with Power steering |
Traction Type: |
4*2 |
Leaf Spring number: |
7/9+6,8/10+8 |
Tire size/type |
9.00-20,9.00R20 |
Engine specification | |||
Engine Model: |
B170 33 |
Engine Brand |
DONGFENG |
Fuel type: |
Diesel |
Displacement(ml) |
5900 |
Emission stand |
Euro 3 |
Power(kw) |
125(170hp)) |
Warranty |
12 months, from the date of supply |
||
Superstructure parameter |
1. Max lifting Weight(kg):2000Kg, Max towing Weight(kg): 5000kg |
||
2. Equipped with 5ton winch, 10mm thickness 20m long steel rope, a pair of L-typePalette fork, two auxiliary wheel, a warning light, 4 straps | |||
Multi-faceted Show of Dongfeng Flatbed Wrecker Truck Show as following:
Tool box of Flatbed Wrecker Truck :
Rear Towing arm & towing fork of Flatbed Wrecker Truck :
Hydraulic Oil Tank of Flatbed Wrecker Truck :
Platform of Flatbed Wrecker Truck :
Signal Light of Flatbed Wrecker Truck :
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. Leading productions include more than 300 types of trucks such as Water truck, Fecal suction truck, sewage suction truck, Garbage truck, Road sweeper, Fuel tank truck, Van truck, Chemical liquid truck, Concrete mixer truck, Pressure vessel, etc.It has registered trademark "CHENLIWEI" and the products code is “CLW”. It has solid technology, flawless inspection, advanced equipments, reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 , the 3C Certification(China Compulsory Certification) and other certifications that export needed. It own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc.
ChengLi Special Automobile is the most important partner of DongFeng , FAW , JAC, FONTON ,Sinotruck and other automlbile company. It not only design and manufacture all kinds of special automobiles and fittings as per the customer’s request ,but also sale DongFeng ,FAW ,JAC, FONTON, North Benz, Sinotruck and other large automobile manufacturer’s chassis, whole vehicle and the spare part.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks always strives for the survival by the quality, pursue of development by efficiency. It has always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea. Credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Production Equipments;
Contact Information;
The above information is just for your reference, if you have any other questions
or need more truck picture or detailed information, please feel free to contact with me via
e-mail or phone, I will try my best to help you. You can count on me. Please check my
contact information as below:
