Small Flatbed Towing Truck Technical Parameters
Equipment:
1.Equipped with hydraulic pressure system, neat-structured,bindings automatic bord.
2.Equipped with high-latitude signal lamp which can guarantee night barrier-cleaning work.
3.Equipped with traction supporting highly flexible crane operated by the hydraulic pressure system.
The technical paramters of this flatbed towing truck for your reference.
[Main Technical Parameters] | |||
Product Name | Road Wrecker | Product Brand | CLW |
Gross Vehicle Weight(Kg) | 8495 | Curb Weight(Kg) | 5800 |
Cab Allowed Persons | 3 | Overall Dimension(mm) | 8000×2300×2500 |
Appr/Dep Angle(°) | 22/9 | F/R Suspension(mm) | 1180/2420 |
Axle No. | 2 | Wheelbase(mm) | 4400 |
Axle Load(Kg) | 3200/5295 | Max Speed(Km/h) | 90 |
Material of flatbed | Checker plate | Thickness of flatbed(mm) | 5.0 |
[Chassis Technical Parameters] | |||
Chassis Model | EQ1081TJ12D5 | Chassis Brand | Dongfeng |
Overall Dimension(mm) | 7695×2250×2350 | Tyre No. | 6 |
Appr/Dep Angle(°) | 22/11 | Tyre Specification | 8.25-16 |
Spring Leaf No. | 11/13+8 | Front Track(mm) | 1770 |
Fuel Type | Diesel | Rear Track(mm) | 1640 |
Emission Standard | Euro Ⅲ | ||
Engine Model | CY4102-C3B | Engine Brand | Chaoyang |
Power (kw) | 100 | Displacement(ml) | 3856 |
The picture of Small Flatbed Towing Truck
As a professional special vehicle manufacturer in China, we can customize almost 300 kinds of trucks for you. Any products information, please feel free to contact me.
