New Dustbin Street Sweeper Truck 8000liters Cleaning Vehicle/Road Sweeper Machine With Snowing Cleaning Equipment

Item

parameter

Product model

Snow removal truck

Overall dimension(mm)

7650*2480*3200

Chassis model

EQ5140KLJ

Wheel base(mm)

4500

Engine model

B190 33

Engine rated power(kw)

140

Second engine

model

Jiangling JX493Q1

Engine rated power(kw/r/min)

57/3600

High-pressure washing

Washing width of water spraying frame(m)

2.5-3.5

Angel of water spraying frame(o)

30 both left and right

Cleaning capacity(m2/h)

25000

Max. cleaning water pressure(Mpa)

10

Cleaning water flow(L/min)

152

Spraying water flow(L/min)

152

Low-pressure washing

Low pressure sprinkling water flow(L/min)

600-800

Width of low pressure washing(m)

≥24

Squirt gun range(m)

38

Working speed

Low-pressure sprinkling

Main engine rev 1200r/min

7(gear I)  14(gearII)

High-pressure sprinkling

Second engine rev1700r/min

0-15

Rated capacity of water tank(L)

7520

Kerb weight(kg)

7495

Max. gross weight(kg)

14490

Max.speed(km/h)

85

Max.gradeability(o)

15

Braking length(m)

≤10

Min. turning diameter(m)

<16

Approach/departure angle(o)

25/20

Min. ground clearance(mm)

350

Low-pressure water pump

65QZB-50/110N

High-pressure water pump&accessories

KL45,P51/135-90

Low-pressure centrifugal

80QSB-60/90

Hydraulic module

QX160-31-300

Oil cylinder

HSGL-32/18E-131
