Home > Manufacturing & Processing Machinery > Crane > Truck Crane > Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane

Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane

Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane photo-1
Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane photo-2
Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane photo-3
Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane photo-4
Dongfeng 4*2 4*4 Type 95 Hp Truck Mouted Crane Sinotruck Crane photo-5
US$ 17,000 - 25,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Construction
Rated Loading Capacity:
3 ton
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or any other port of China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Construction
Rated Loading Capacity 3 ton
Rated Lifting Moment 961KN.m
Max. Lifting Load 3.2ton
Max. Lifting Height 5m
Span 1.3m-3.5m
Place of Origin Hubei, China
Brand Name CLW
Model Number CLW
Certification CCC, ISO , SGS, BV
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

CLW Group_ChengLi Special Automobile Co.,Ltd, Which is a big and famous special function truck manufacturer in China, We produce many kind of special function vehicles, also include the truck mounted crane.Currently we produce the truck mounted crane range from 3 ton to 25 ton, heavy duty type from 25 ton to 200 ton.Welcome for your inquiry.

Product Description

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

ItemUnitDescription
Model Dongfeng Truck Mounted Crane
Dimensionmm5995*1980*2950
Cargo Boxmm3500*1880*400
Curb WeightKg3915
G.V.WKg6495
Wheel Basemm3300
F/R track basemm1506 / 1466
F/R Axle-LoadKg2500 / 4000
SuspensionSteel Spring
Approach/Departure angle.19 / 15
Traction systemType4*2
Tire SpecificationModel7.00-16 , 6 Unit +1 Spare Unit
Max speedKm/h90
Engine ModelCY4102-C3F
Emission/Kw3856 cc, 70 Kw
Horse Power95 Hp
Power235 N.m-1400~1800r/min
TypeDiesel, 4cylinder, Turbocharge , water cooling.
BrandDongfeng Chaoyang Engine Power Co.,Ltd
Gear boxmodel5F & 1R  ,  Manual
BrandDongfeng brand
ClutchType¢430mm ,Hydraulic control with air booster, pulling
ElectronicV12
Fuel TankLiter80
Brake SystemTypeFull air brake system, split pneumatic circuit , parking spring brake acting on rear axles , exhaust  brake
CabPerson3
TypeManual Reversable, Manual Windows,
SteeringTypePowering
InstallingLHD or RHD
Air ConditionYesRadio, CD.
Crane Specification
ModelWorking Range(radius)Lift heightDistance of Support leg
mmm
SQ3.2SA25.86.83.1
Length2.1 m3.7 m5.8 m
Lifting32001600900
More photos showing

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck craneDongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck craneDongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane



Packaging & Shipping

Transporting mainly by Bulk ship and RORO ship.

1. Bulk Ship loading photo showing.

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

2. RORO Shipping loading photo showing.

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

3. Special loading method, Some truck could loading into a container, GP type or HQ type container.

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

Company Information

Our company is a big and famous special function truck manufacturer in China, We produce many kind of trucks, water tank truck

oil tank truck, oil tank trailer.

Vaccum suction truck.

Garbage Truck

high platform working truck.

Dump truck.

concrete mixer truck, concrete pump truck.

Refrigerator truck.

Wrecker truck.

Road sweeper truck.

Chemical liquid transporting truck.

All kind of semi trailer.

LPG gas tank, LPG truck and trailer.

Fire fighting truck.

Welcome to your inquiry.

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

Dongfeng 4*2 4*4 type 95 Hp truck mouted crane sinotruck crane

FAQ

CLW Group--- ChengLi Special Automobile Co.,Ltd

1. What do we do ?

We are an integreted special truck manufacturer and sale.  all trucks are new customized according to customer requirement.

2.Is there any branch Company in oversea ?

Currently there is no oversea branch.

3.What's your warranty of your product ?

One year warranty time or 10000 Km driven.

4. How to buy a truck from your company ?

Welcome to your inquiry about our trucks, firstly please check with the sales manager for your demand in detail, then sales manager will make an offer to you according to your demand, If offer is acceptable, sales manager will send you proforma Invoice which will show our company account( we never provide personal account for customer), Please make the Transfer to our company account, then we will arrange production when confirming.

5. What about the payment method ?

We accept T/T, and L/C.

T/T 30 % in advance, we could arrange production, then left 70% should be done before truck loading on ship.
