Home > Transportation > Trailer > Truck Trailer > 3 Axles Aluminum Alloy Chemical Liquid Transport Semitrailer 41m3

3 Axles Aluminum Alloy Chemical Liquid Transport Semitrailer 41m3

US$ 10,000 - 48,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Type:

Semi-Trailer

Material:

Aluminum / Alloy

Certification:

Other, 3c

Contact Supplier Request Quote Chat Now

Chengli Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Semi-Trailer

Material Aluminum / Alloy

Certification Other, 3c

Size 12700*2500*3975

Max Payload 31000

Place of Origin Hubei, China

Brand Name CLW

Model Number CLW9402GHY

3 axles aluminum alloy chemical liquid transport semitrailer 41m³

Chemical liquid transport semitrailer is also called chemical truck,mobile transport truck,tanker truck semitrailer,prssure vessel truck,etc, widely used in xylene ,ethanol , acetic acid and other chemial liquid's transportion and storage. We can supply tanker ranged from 4000L to 45000L,Tanker Semitrailer ranged from 30000L to 6000L. Experience of ten years of manufacturing pressure vessel ensure reliable quality. Use this type of semitrailer can improve transport efficiency 30-50%, reduce cost 30% -40%, reduce fuel consumption 20

%- 30%.

Technical Parameter of 3 axles aluminum alloy chemical liquid transport semitrailer 41 m³

Main Technical Parameter
Product Model	CLW9402GHY chemical liquid transport semitrailer	*Overall Dimension(LWH)(mm)*	12980×2500×3600
Tank Volume(m³)	41	*Tank Dimension(mm)(lengthlong axle* short axle)**	12500×2480×1700
Gross weight (kg)	40000	Approach/ departure angle (° )	-/12
Payload(kg)	31000	Wheelbase(mm)	6730+1310+1310
Curb weight(kg)	9000	Rear tread(mm)	1840/1840/1840
Front/ rear suspension(mm)	-/2130	Leaf Spring number:	-/8/8/8
Axle number	3	Front/Rear axle load(Kgs)	-/24000(three-axis combined)
Tire size	11.00-20 12PR,11.00R20 12PR	Tire No:	12
Other equippment	Protective material: magnesium aluminum alloy
	Use the tractor equipped with speed limit device better
	Equipped with antilock braking system and ABS
Warranty	12 months, from the date of supply

This chemical liquid transport semitrailer show as following:

Brief Introduction of Company:

ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.

Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.

We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.

ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.

Our Certificates:

Parts of Trucks Exported:

If you have any questions, pls feel free to contact with me via e-mail or phone, I will try my best to help you. You can count on me. Please remember as below:
