CLW 3 Axle Fuel Trailer 50000 Liters with DONGFENG Tracotor Head
- 300 Set / Sets per Month
- any port in China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
CLW 3 line six-axis 100ton Low bed Semi trailer for sale
-
Price promotion CLW 3 axis 55m3 Fuel Trailer with FAW tractor
-
3 Axles Aluminum Alloy Delivery oil semi-trailer 60m3
-
3 Axles Oil Tank Trailer 49000L With FONTON Tractor
-
CLW 3 Axis Container Framework
-
33Ton 3 Axles Refueling Semitrailer with Shacman Tractor
Product Details
Type | Semi-Trailer | Material | Steel | |
Certification | Other, ISO9001, 3C | Size | 12980*2500*3820 | |
OEM No. | CLW9400 | Max Payload | 42500 | |
Place of Origin | Hubei, China | Brand Name | CLW9400 | |
Model Number | CLW9400 |
Product Description
CLW 3 Axle Fuel Trailer 50000 Liters with DONGFENG Tracotor Head
Fuel Trailer 50000 Liters is also called cargo semitrailer ,mobile transport truck,tanker truck semitrailer,etc, widely used in transporting and discharging gasline, diesel and other fuel product. We can supply tanker ranged from 4000L to 45000L,Tanker Semitrailer ranged from 30000L to 6000L. Experience of ten years of manufacturing pressure vessel ensure reliable quality. Use this type of semitrailer can improve transport efficiency 30-50%, reduce cost 30% -40%, reduce fuel consumption 20%- 30%.
Main Parameter of CLW 3 Axle Fuel Trailer 50000 Liters with DONGFENG Tracotor Head
Whole truck main technical parameter | |||
Product Model | CLW Fuel Trailer 50000 Liters | Overall Dimension(L*W*H)(mm) | 12980×2500×3820 |
Tank Volume(L) | 50000 | Tank Dimension(mm) | Front-end( 4200×2480×1800 ) rear-end( 8300×2480×2000 ) |
Payload(kg) | Approx 42500 | Front/ rear suspension(mm) | -/1860 |
Curb weight(kg) | 10150 | Leaf Spring number: | -/8/8/8, -/10/10/10 |
Axle number | 3 | Front/Rear axle load(Kg) | -/39000 (three-axis combined) |
Wheelbase(mm) | 7200+1310+1310 | Rear tread(mm) | 1840/1840/1840 |
Tire size | 11.00R20 12PR or 12R22.5 12PR | Number of Tire: | 12 |
Warranty | 12 months, from the date of supply | ||
Remarks | 1. One compartment, can select more compartments to load different oil | ||
2. Use the tractor equipped with speed limit device better | |||
3.Tank material: 6mm carbon steel or stainless or aluminum alloy, 90# king pin, 13 ton axles, 28 ton outrigger, two Gravity valves, one rear ladder, one tool box, two fire extinguisher, ground wire , 2 oil pipe |
Main Parameter of 375 Hp DONGFENG Kinland 6*4 Tractor Truck Head
Main Technical Parameter | |||
Product Model | DONGFENG Tractor Truck Head | Overall Dimension(L*W*H)(mm) | 6960×2500×3700 |
Curb weight(kg) | 8800 | Total Mass of Quasi-trailer(Kg) | 60000 |
Wheelbase(mm) | 3300+1350 | Axle number | 3 |
Steering Type | LHD with Power steering | Max Speed (km/h) | 95 |
Approach/ departure angle (° ) | 18/32 | Front/ rear suspension(mm) | 1500/810 |
Cab capacity | 2,3 | Cab Type | High proof with two sleeper,air conditioning |
Chassis Technical Parameter | |||
Product Model | DFL4250 | Manufacturer | DONGFENG Motor Co., Ltd |
Gear Box | ZF Ecosplit 16S1650 (Fuller 16 speeds and 2 reserve | Transmission type: | Manual |
Brake System | Double-circulate brake system with ABS | Traction Type: | 6*4 |
Leaf Spring number: | 3/4,3/10 | Front/Rear axle load(Kg) | 7000/13000( rear two axles combined) |
Tire size | 315/80R22.5(vacuum tire) | Number of tire | 10 with a spare |
Engine specification | |||
Engine Model: | dCi375-30 (Six-cylinder in-line, four-stroke, four-valve, common rail direct injection, turbocharged and intercooled) | Engine Brand | DONGFENG ( technology from France Renault) |
Emission stand | Euro 3 | Displacement(ml) | 11120 |
Fuel type: | Diesel | Power(kw) | 276(375HP) |
Other equipment | 1.Gear Box optional FAST 12JS180TA(Fuller 12 speeds and 2 reserve) | ||
2.Equipped with ABS and driving recorder , 90# saddle | |||
3.Optional Equipped with speed limit device, (Limit speed 80km/h) | |||
Warranty | 12 months, from the date of supply |
Multi-faceted show of CLW 3 Axle Fuel Trailer 50000 Liters with DONGFENG Tracotor Head :
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
