3 Axles Fuel Tank Trailer Truck 42000L with SHACMAN Tractor
Fuel Tank Trailer Truck is also called mobile tanker semi trailer,tanker semi trailer truck,oil semi trailer truck,etc, widely used in gasoline,crude,lubricants,coal tar and other flammable gases's transportion and storage. We can supply Fuel Tanker Semitrailer ranged from 30000L to 6000L, Fuel tanker ranged from 4000L to 45000L, Experience of more than ten years of manufacturing pressure vessel ensure reliable quality.
Production Notes:
1. With ISO9001, ISO14001, 3C Certificates
2 Factory direct sale
3 10 year' Professional technology
4 Load 42000L, with SHACMAN tractor
Main Parameter of 3 Axles Fuel Tank Trailer Truck 42000L with SHACMAN Tractor
Whole truck main technical parameter | |||
Product Model | CLW Fuel Tank Trailer Truck | Overall Dimension(L*W*H)(mm) | 11000×2500×3850 |
Tank Volume(L) | 42000 | Tank Dimension(mm) | Front-end(3900×2480×1800) rear-end(6800×2480×2040) |
Gross weight (kg) | Approx 39800 | Approach/ departure angle (° ) | -/22 |
Payload(kg) | Approx 28000 | Front/ rear suspension(mm) | -/1410 |
Curb weight(kg) | 11800 | Leaf Spring number: | -/8/8/8 |
Axle number | 3 | Front/Rear axle load(Kg) | -/39000 (three-axis combined) |
Wheelbase(mm) | 5760+1310+1310 | Rear tread(mm) | 1840/1840/1840 |
Tire size | 11.00R20 12PR | Number of Tire: | 12 |
Warranty | 12 months, from the date of supply | ||
Remarks | 1. Protective material: carbon steel, storage medium: gasoline | ||
2. Use the tractor equipped with speed limit device better | |||
3.Tank material: 6mm carbon steel, 90mm saddle | |||
Main Parameter of Shacman Delong 385HP 6*4 Tractor
Main Technical Parameter of Shacman 385HP 6*4 Tractor Unit | |||
Product Model | SX4254NT294C | Overall Dimension(L*W*H)(mm) | 6635×2490×3640 |
Curb weight(kg) | 9000 | Total Mass of Quasi-trailer(Kg) | 39800 |
| Wheelbase(mm) | 2925+1350 | Steering Type | LHD or RHD with Power steering |
| Axle number | 3 | Max Speed (km/h) | 92 |
Cab capacity | 3 | Cab Type | F3000 Flat proof Cab, air conditioning |
Chassis Technical Parameter | |||
Gear Box | FAST 12JS160T (Fuller 12 speeds) | Transmission type: | Manual |
Brake System | Breathe brake system with ABS | Traction Type: | 6*4 |
Tire size | 11.00-20,11.00R20 16PR, | Number of Tire | 10 with a spare |
Engine specification | |||
Engine Model: | ISME385 30 | Engine Brand | American |
Emission stand | Euro 3 | Displacement(ml) | 10800 |
Fuel type: | Diesel | Power(kw) | 283/385HP |
Main parameter | 1.Equipped with ABS and driving recorder | ||
2. 50# or 90# kingpin | |||
Warranty | 12 months, from the date of supply | ||
Multi-faceted Show of Fuel Tank Trailer Truck show as following:
More Fuel Tank Trailer Truck show as the following:
1, Packaging: nude or waxing;
2. Shipping: in the container or Ro-Ro ship or bulk ship according to the customer’ order or requirement;
1. Factory direct supply: reliable quality and fast delivery;
2. Warranty; from the date of receiving, in normal use within 30000kh or within one year, we will repair for free, but the wearing parts and electrical parts are not included. After one year, we only charge cost when the question occurs;
3. Tracking service: lifelong
4. Chassis question: when the question occurs, please find the local nearest Service Station for repair or maintenance, or call us if the local have no Chassis Service Station;
5. Spare Parts: Superstructure spare parts is sent by ourselves, we only charge cost; Chassis spare parts is sent by the local Service station, if the local have no chassis service station, please call us freely.
6. OEM Ability: We can customize the truck according to your request, such as material, size, color, paint, logo, etc.
7. Warm tip: please operate, use, and maintain the truck according to our manuals and Instructions. When the question occurs, please call us freely.
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our Certificates:
Production Equipments:
1. Are you manufacturer or trading company?
We are direct manufacturer;
2. Min Order Quantity:
One unit or one sets;
3. Handling Time:
Within one day;
4. Payment Terms:
30% deposit, 70% balance before shipment by TT or Irrevocable LC at sight;
5. Specified delivery date from the Date of Order:
Depend on the detailed request and purchase order quantity.
6. Contact Information:
For any question or request, please contact with me freely according to the following information:
