sewage suction truck
1Equipped with special vacuum pump(rating rotate speed=1400r/m,min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise)
2Equipped with power take off, transmission shaft, high pressure sewage tank, pipe network, sewage pipe for observing and cleanout equipment
3Time for full suction<5min
If you have any special demands about our trucks please let me know
Item | unit | parameter | |||
Vehicle model |
| CLW5108GXWWT Sewage Suction Truck | |||
Chassis model |
| EQ1101GLJ | |||
Overall dimensions | mm | 7590×2470×2810 | |||
| Factual cubage | L | 6000 | ||
GVW | kg | Appro×10495 | |||
Rated loading capacity | Appro×4000 | ||||
Mass in working order | Appro×6300 | ||||
Body internal dimensions | mm | / | |||
Wheel base | 3950 | ||||
F/R track base | 1900/1800 | ||||
Approach/departure angle | ° | 33/22 | |||
Exhaust/hp | ml/kw | 5883/118 | |||
Max speed | km/h | 95 | |||
Tire specification | 9.00-20 | Engine type | EQB160-20 | ||
Traction system | 4×2 | transmission | 6-speed with over drive | ||
Number of axles | 2 | Electric system | 24v | ||
Operation control system | Electrically hydraulic control | Allowable passengers in cab | 3 | ||
Equipment | 1.Equipped with special vacuum pump(rating rotate speed=1400r/m,min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, clockwise) 2.Equipped with power take off, transmission shaft, high pressure sewage tank, pipe network, sewage pipe for observing and cleanout equipment 3.Time for full sucktion<5min | ||||
Engine | DongFeng Cummins Environmental Protection,supercharge,diesel engine | ||||
Production cycle | 10-15days | ||||
Warranty | 12 month,from the date of supply | ||||
Hubei Chengli Special Automobile Co., Ltd., which is appointed by the Development and Reform Commission of China, is a professional manufacturer of special automobiles for landscaping, petrochemical, and environment cleanness. Our labels are CLW and SNJ. Our company has independent export authority, and has a lot of overseas clients. Our leading products include more than 8 series and 100 types of trucks such as water trucks, tank trucks, garbage trucks, fecal suction trucks, sewage suction
