dongfeng 5 m3 concrete mixer truck
Concrete mixer truck, concrete mixer dum, which is mainly used for concrete transporting, from the concrete mixer plant to the destination, transporting by concete mixer truck, it could make the concrete stable, so that it could be the same when producing in plant.
CLW Group_ChengLi Special Automobile Co.,Ltd, Which is a big and famous special vehicle manufacutere in China, we produce Concrete mixer truck, concrete pump truck, and the concrete pump trailer.
Currently concrete mixer truck type.
1~3 m3 valid concrete mixer truck, 4*2 type
5~7 m3 valid concrete mixer truck, 6*4 type
8 m3 valid concrete mixer truck, 8*4 type
Concrete pump truck , 28 m design, with the concrete pump trailer.
Welcome for your inquiry.
- dongfeng 5 m3 concrete mixer truck
- Specification in detail
| Item | Unit | Description | ||||||||
| Model | Dong Feng brand Concrete Mixer Truck | |||||||||
| Dimension | mm | 9000*2500*3950 | ||||||||
| Mixer drum | m3 | Inside 4.9 m3 valid mixer drum | ||||||||
| Curb Weight | kg | 14050 | ||||||||
| Wheel Base | mm | 3650+1350 | ||||||||
| Ground Clearance | mm | 450 | ||||||||
| F/R track base | mm | 2050 / 1850 | ||||||||
| F/R Axled-Load | Kg | 7000 / 13000 / 13000 | ||||||||
| Approach/Departure angle | . | 30 / 16 | ||||||||
| Tire Specification | Model | 11.00R20 , 10 + 1 Spare Unit | ||||||||
| Traction system | Type | 6*4 | ||||||||
| Max speed | Km/h | 75 | ||||||||
| Engine model | Model | C300-33 | ||||||||
| Emission/Ps | 8300 cc , 221 Kw | |||||||||
| Horse Power | 300 Hp / 2200 r/min | |||||||||
| Mix Power | 1125 N.m-1500 r/min | |||||||||
| Type | Diesel, 6 cylinder, Turbocharge , Inter-cooling | |||||||||
| manufactuere | Dong Feng Cummins Engine Co.,Ltd | |||||||||
| Gear box | Type | 9F&1R, Manual | ||||||||
| Electric system | V | 24 | ||||||||
| Cab | Person | 3 | ||||||||
| Type | Reversable, Manual | |||||||||
| Steering | Type | Powering | ||||||||
| Installing | LHD or RHD | |||||||||
| Air condition | Option | CD, Radio,Mp3 | ||||||||
| Remark: |
1.)Speed reducer: Italy PMP 2.)Hydraulic pump:Italy PMP 3.)Hydraulic Motor:Italy PMP 4.)Installed small water tank 450L for mixer drum. |
|||||||||
- Some photos showing
- dongfeng 5 m3 concrete mixer truck
Transporting mainly by Bulk ship and RORO ship.
1. Bulk Ship loading photo showing.
2. RORO Shipping loading photo showing.
3. Special loading method, Some truck could loading into a container, GP type or HQ type container.
Our company is a big and famous special function truck manufacturer in China, We produce many kind of trucks, water tank truck
oil tank truck, oil tank trailer.
Vaccum suction truck.
Garbage Truck
high platform working truck.
Dump truck.
concrete mixer truck, concrete pump truck.
Refrigerator truck.
Wrecker truck.
Road sweeper truck.
Chemical liquid transporting truck.
All kind of semi trailer.
LPG gas tank, LPG truck and trailer.
Fire fighting truck.
Welcome to your inquiry.
CLW Group--- ChengLi Special Automobile Co.,Ltd
1. What do we do ?
We are an integreted special truck manufacturer and sale. all trucks are new customized according to customer requirement.
2.Is there any branch Company in oversea ?
Currently there is no oversea branch.
3.What's your warranty of your product ?
One year warranty time or 10000 Km driven.
4. How to buy a truck from your company ?
Welcome to your inquiry about our trucks, firstly please check with the sales manager for your demand in detail, then sales manager will make an offer to you according to your demand, If offer is acceptable, sales manager will send you proforma Invoice which will show our company account( we never provide personal account for customer), Please make the Transfer to our company account, then we will arrange production when confirming.
5. What about the payment method ?
We accept T/T, and L/C.
T/T 30 % in advance, we could arrange production, then left 70% should be done before truck loading on ship.
