This is a new generation of asphalt and stone crushing synchronous seal paver with the latest scientific and technological achievements of Chengli Special Automobile Co.,Ltd
The appearance of the synchronous vehicle breaks through that of traditional pavement construction vehicle.
Structure and coating are more high-end and practical. The construction operation is more convenient and quick for the construction personnel.
Construction efficiency has been greatly improved. After long-term technology research of ICOM people, uneven spreading of stone chips of domestic similar products, clear strip in the middle of the road, few stone chips on both sides and other defects have been effectively corrected.
Spreading uniformity of stone chips is improved and spreading width of stone chips is effectively guaranteed. The vehicle can be widely used in synchronous seal operation of each grade of highway. It is cost-saving, wear-resisting, anti-skidding and waterproof.
After construction traffic can be quickly restored. It is suitable for waterproof of road surface and bridge deck, crushed stone seal technology of the lower seal coat and pavement maintenance and repairing.
Parameters Of Synchronous Chip Sealer:
Mass parameter: | ||||||
Kerb Weight(kg) | 21200 | Total Weight(kg) | 31000 | |||
Rated loading Weight(kg) | 9670 | Dimension(mm) | 12000×2500 ×3730 | |||
Chassis Parameter: | ||||||
Chassis Model | ZZ1317N4647C | Tyre model | 12.00-20,12.00R20 | |||
Wheelbase (mm) | 1800+4600+1350 | Tread mm | 2022/1830 | |||
Engine parameter: | ||||||
Engine model | WD615.95 | Manufacturer | China Heavy Duty Truck Group Co., Ltd. | |||
Max.Power(kw) | 247 | Max. Torque(N.m) | 1300/1600 | |||
Fuel | Diesel | Displacement(ml) | 9726 | |||
Chip sealer specification: | ||||||
Tank Capacity(L) | 8000 | Spray width | 3800mm | |||
Hydraulic pump model | CBQL-E563 | Spray Value | 0.5-3.0(Kg) | |||
Hydraulic motoe | L2F63W2P2(Liyuan) | Insulation Thickness | 50mm | |||
Controller | ZMTB-3D | Nozzles | 28 | |||
Generator(Converter) | YT6800E | Burner | G20(Riello)(N:2 ) | |||
Asphalt pump | QGB450/0.8(Shanggui) | Chipping capacity(m³) | 12m3 | |||
HTF pump | GRY40-25-160 | Cycloid motor | OMR-80 | |||
Advantages :
1. exclusive use of hydraulic drive mode, no need to add any auxiliary power make the operation more simple and convenient.
2.exclusive use of efficient oil boiler to heat up, so that the temperature rise would be enhanced greatly speed, breaking the traditional flue heating method.
3.The device can be achieved within a stone chip spreader hopper lifting construction, more convenient and culvert construction, bridge construction, as well as the construction of the curve;
4.The device is complete with electrical control, high degree of automation ,, can accurately calculate the equipment during the construction and stone chips spreading asphalt spray volume amount of how much;
5. material door control using inclinometer, ensuring the accuracy of the device material;
uce the construction of labor intensity, saving human resources, reduce construction costs and improve efficiency, quality of work;
7. machine stable, spreading evenly, sprinkle freely adjust the width of the asphalt material spreading;
8.ensure good thermal insulation performance index ≤20 ℃ / 8h, and durable anti-corrosion;
9. You can spray a variety of asphalt media, spreading from S3 ~ S24mm of stone;
10. equipment using high precision machining nozzle, so that each spray nozzle spray consistency and effectiveness is fully guaranteed;
11. overall operating more humane, with remote control, there are on-site operation, the operator has brought great convenience;
12. through the perfect constant pressure hydraulic system and electrical control devices combine to achieve a scratch spray;
13. whole number of improvements after construction, reliable performance, easy operation and maintenance, cost-effective.
Intelligent synchronous chip sealer is the special construction machinery of international stature and could be applied into the simultaneous spraying work of highways.It could simultaneously spray asphalt and aggregate or respectively spray them. It features cost saving, wear resistance and anti-skidding of road surface and good waterproof performance. The traffic could be recovered soon once the construction is done. It is suitable for the construction of highways at different grades.
Images of Synchronous Chip Sealer:
This is a new generation of asphalt and stone crushing synchronous seal paver with the latest scientific and technological achievements of ICOM Machinery. The appearance of the synchronous vehicle breaks through that of traditional pavement construction vehicle. Structure and coating are more high-end and practical. The construction operation is more convenient and quick for the construction personnel.
Construction efficiency has been greatly improved. After long-term technology research of ICOM people, uneven spreading of stone chips of domestic similar products, clear strip in the middle of the road, few stone chips on both sides and other defects have been effectively corrected. Spreading uniformity of stone chips is improved and spreading width of stone chips is effectively guaranteed. The vehicle can be widely used in synchronous seal operation of each grade of highway. It is cost-saving, wear-resisting, anti-skidding and waterproof. After construction traffic can be quickly restored. It is suitable for waterproof of road surface and bridge deck, crushed stone seal technology of the lower seal coat and pavement maintenance and repairing.
Howo Synchronous Chip Spreader is shipped by bulk,ro-ro or container .
Howo Synchronous Chip Spreader Manufacture : Chengli Special Automobile Co.,Ltd
WELCOME TO VISIT OUR FACTORY !
