Home > Products > truck scale > Electric truck scale
Electric truck scale
- 20 Set / Sets per Month
- xingang
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Hebei, China | Brand Name: | JC | Model Number: | as following |
Type: | Truck Scale | Power Supply: | as following | Display Type: | as following |
Rated Load: | as following | Accuracy: | as following |
Product Description
Specifications
The electric truck scale can be operated conveniently. It is suitable for industrial and mining enterprise, sea port, etc.Specification:
Type | SCS-20 | SCS-30 | SCS-50 | SCS-60 | SCS-80 | SCS-100 |
Outline Dimensions (m) | 3x7 | 3x7 3x12 | 3.5x14 | 3.5x14 3.5x16 | 3.5x16 3.5x18 | 3.5x18 3.5x21 |
Number of the Platform | 1 | 1 2 | 2 | 2 | 2 3 | 3 3 |
Transducer (T)/Number |
10/4
| 20/4 10/6 | 20/6 | 20/6 20/6 | 20/6 20/8 | 20/8 20/8 |
Height (m) | 0.32 | 0.32 | 0.32 | 0.32 | 0.32 | 0.32 |
Maximum Capability (T) | 20 | 30 | 50 | 60 | 80 | 100 |
Scale Interval (kg) | 10 | 10 | 20 | 20 | 20 | 50 |
Accuracy of the Scale | OIML (third) |
Performance Parameter:
1. Working conditions of meter:
Temperature: -10-- +40 Relative humidity (RH): 95%
2. Working conditions of transducer:
Temperature: -20-- +65
3. Power: 220V AC +10% -- -15% 50Hz ±1Hz
