Home > Products > Twisting machine > Ring Twister Doubling In Spinning Two Sewing Twisting Machine
Ring Twister Doubling In Spinning Two Sewing Twisting Machine
- 20 Set / Sets per Month
- NINGBO PORT
- T/T Credit Card
Product Details
Condition: | New | Application: | ROPE ,YARN,FISHING NET ETC | Type: | Other, Twisting Machine, ACS-T2.1 |
Production Capacity: | 20m/min | Place of Origin: | Zhejiang, China | Brand Name: | ROBTEAM |
Model Number: | ACS-T2.1 AS5594 | Spinning Method: | Ring Spinning | Automatic: | Yes |
Dimension(L*W*H): | 5500*1320*2080mm | Weight: | 4200kgs | Power(W): | 14.3kw |
Certification: | CE,ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Ring Twister Doubling In Spinning Two Sewing Twisting Machine
best price high speed jute twisted rope making machine
Performance and Characteristics:
Your satisfaction is our huge motivator!
This machine could process all kinds of strings for chemical filament, textured yarns, glass fiber, fishing net, twine, wool, fabric cord, cotton yarn, carpet, canvas and etc.
Main Technical Parameters:
Type | ACS-T6150 | ACS-T7165 | ACS-T8200 | ACS-T10254 | |
Spindle amount | 144 | 100 | 48;56-72 | 24;30-42 | |
spindle pitch | 180 | 200 | 250mm | 340 | |
spec of ring | 140×25.4 | 165×25.4 | φ200×25.4mm | φ254×38.1mm | |
Ring Lift | 300 | 300 | 300-350 | 300-350 | |
Spindle speed | 2500-4000 | 2500-4000 | 2000-3800rpm | 180-2100 | |
Direction of lay | S/Z | S/Z | S/Z | S/Z | |
Capacity of Finished Product Package | 900-1100g | 2800-3500g | 3500-5000g | 7000-11000g | |
Twist Range | 55-620 | 55-620 | 45-520 | 15-405 | |
Spindle motor power | 15 | 15kw | 18.5kw | 11kw | |
Dia. of roller | φ61 φ80 | φ61 φ80 | φ61 φ80 | φ61 φ80 | |
Roller motor power | 1.1kw×2sets | 1.1kw×2sets | 1.1kw×2sets | 1.1kw×2sets | |
Lifting motor power | 1.1kw | 1.1kw | 1.1kw | 1.1kw | |
overall dimension | 11820×1200×2000 | 12500×1200×2000 | 10920×1320×2080 | 5495×1320×2080 | |
Application | yarns | 21pcs 3 - 38strands | 21pcs 5 - 45strands | 21pcs 18 - 170strands | 21pcs 18 - 170strands |
fiber | 1500D-5000D fiber | 1500D-6000D fiber | 650D-15000D fiber | 650D-15000D fiber | |
polyethylene | 36fe×3-25 strands PE twisting or strands twisting | 36fe×10-40strands PE twisting or strands twisting | 36fe×3-25 strands PE twisting or strands twisting | 36fe×3-25 strands PE twisting or strands twisting |
ring twister doubling twisting machine twisting machine Type ACS-T2.1
in spinning two twisting machine twisting machine Spindle No. 12,24,30-42
sewing twisting machine twisting machine Spindle pitch 180-340mm
ring twister doubling twisting machine twisting machine Ring size 254mm8.1mm or as per customer's request
in spinning two twisting machine twisting machine Lifting tranverse 300-350mm
sewing twisting machine twisting machine Spindle speed 180-2100rpm
ring twister doubling twisting machine twisting machine Lay direction S/Z
in spinning two twisting machine twisting machine Bobbin winding capacity 0.9-11kgs
sewing twisting machine twisting machine Twist range 15-620tpm
Pre-sales services
* Any concerns of our machine by email/phone will be replied ASAP within 24 hours
* Inquiry and consulting support
* Sample testing support
* View our factory
After-sales service
*Traning how to install the machine ,tranning how to use the machine
*Engineers are avaiable to service machinery overseas
*One year guarantee for the machine expect the spare part ,we can supply lifelong technology service to slove any problem form you .
1. Q: Are you a factory or trading company? How many people work in your company?
A: We are a factory .Wenzhou Ebey machine manufacture co.,ltd is a professional maufactuer of rope making machine line to make different kinds of rope ,auto cutting and sewing machine for pp woven sack,printing machine ,reycling machine etc and now we have more than 100 years till this year .
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Wenzhou City, Zhejiang Province, China, about 10 minutes from Aojiang train station and 1 hour from Wenzhou airport. It’s very convenient.
3. Q: Why choose us ?
A: Ablity: we are the first company who realize full automatic system on rope production line (contain yarn making machine ,twisting machine and rope making machine etc .) in China.
4. Q: How does your factory do regarding quality control?
A: Quality is priority." We always attach great importance to quality controlling from the beginning to the end. We have our own R&D department for researching new technology and improve machine .Our factory has passed ISO9001:2000 and we have got CE certificate for our machine .
5. What's your machine's after service ?
A: We have very good after sales service: After you purchase our machine we will send our engineer to your factory to install the machine and train your worker.But our machine is easy to operate ,because our machines are full automatic control by PLC and touch screen ,normally don't need our enginner to install and debug the machine ,it can save much time and money.
ring twister doubling twisting machine twisting machine Drive motor power 11-18.5kw
