China Manufacure quinoa Vibration Cleaning Sieve
Specifications:
TQLM-series Rotary Flat Screen is mainly using planar rotary motion and equipped with corresponding specifications of screen surface to separate impurities from raw grain in order to achieve the purpose of cleaning raw grain. It can be used in the cleaning process of grain and cooking oil processing plants and grain crushing workshop of distillery to remove impurities from raw grain according to grain size, meanwhile can remove parts of light impurities and can also be used in cleaning wheat, corn, rape seed, soybeen, barley, rice, peanuts, etc.
Materials of design:
1. The equipment is welded by high qualified steel.
2. The drive motor adopts Siemens or Wannan motor (a leading motor manufacturer in China which is located in the south of Anhui Province.
3. The steel of screen mesh is made of manganese steel punched holes, wear-resistance, longer service life.
4. The driving mechanism adopts imported Japan NSK bearings.
Treatment of Exterior:
1. All the frames have been chemically processed: acid pickling, phosphating, and anti-rust treatment.
2. Anti-corrosive primer has been sprayed firstly, then finishing coating adopts famous high quality fade-proof stoving varnish.
3. The surface is glossy, firm and not easy to fade or drop, with strong scratch-proof ability.
Technical Parameters:
Types | Output (t/h) | Power (kw) | Rotation rate (rpm) | Air volume (m³/h) | Weight (kg) | Screen turning radius (mm) | Dimension of whole machine (L*W*H) |
TQLM100a | 6~9 | 1.1 | 386 | 3200 | 630 | 6~7.5 | 2042*1448*1409 |
TQLM125a | 7.5~10 | 1.1 | 386 | 4500 | 800 | 6~7.5 | 2042*1698*1409 |
TQLM160a | 11~16 | 1.5 | 386 | 5600 | 925 | 6~7.5 | 2042*2146*1409 |
TQLM200a | 15~20 | 2.2 | 386 | 7200 | 1100 | 6~7.5 | 2042*2546*1409 |
High Performance quinoa cleaning machines details:
Applications:
Our Advantages:
1) Huge stocks can meet your urgent demand.
2) As a manufacturer, we can ensure high quality machines & competitive price for you.
3) We have our own factory, can provide you with high quality low price products.
Workshop and Facilities:
Company Information:
Luohe Hualiang Machinery Co., Ltd is a professional manufacturer of designing and installing 30-500T complete set of flour milling machinery, which designed with a compact structure, steel structure, or storey style, is easily installed and operated, requires a low initial investment.
More Choices:
Packing Pictures:
FAQ:
1) What mode of transportation do you have?
Sea transportation.
2) What are the acceptable payment methods?
T/T, 30% deposit, 70% balance before shipment or L/C at sight.
Our Services:
Engineers Overseas Aftersale Service are available.
All HUALIANG manufactured machines will be guaranteed with spare parts and service for one year upon the receiving of shipment.
Contact Us:
Luohe Hualiang Machinery Co., Ltd.
Sophie Song
Email: sophiesong2000 at outlook dot com
Tel:+86-395-2353699
Mobile/whatsapp:+ 86 -15515418665
Skype:live:sophiesong2000
Send Inquiry to This Supplier
