China New Design Concrete Table Vibrator

FOB Price

US$ 500 - 6,000 / Set

1 Set(Min. Order)

Port Qingdao Dalian Shanghai
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	DY
Model Number	ZDP-500*500	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

concrete table vibrator : Wooden packing. the packing size should be according to the actual size.

Product Description

concrete table vibrator

Product detailed introduction

working principle	Vibrating feeder is make up of vibrating frame, vibrator, spring bearing, transmission device, etc. The vibrating power comes from vibrator, The vibrator is contains two fixed eccentric shafts with jogged gears, the motor transmits power through belt and drives one eccentric shaft, the other eccentric shaft moved through the gears, two eccentric shafts spin in the opposite way, which helps transfer materials from hopper to receiving device evenly and continuously.
Advantages	1.Simple structure, work reliable, light weight, small size, easy to install.
	2. Table height is adjustable, It is suitable for production line.
	3. .Infinitely variable speeds .In modeling process, without damage the model, we can get better compaction results.
	4.Fine powders,particle, liquid all can pass it and do not block .
Application	1.Vibrating feeder can feed block or granule materials from the material storage to charging device evenly and continuously. It can realize even feeding for crushers in sandstone production line and make rough screening for materials. 2.Widely applied in combined operation of crushing and screening in the industries like metallurgy, mine, mine selection, building materials, chemicals, etc.

The picture show of concrete table vibrator

technical parameter of concrete table vibrator

Model	Aera(square meter)	powder(kw)	Amplitude(mm)	Weight(kg)
ZDP-500×500	0.25	2×0.25	2-5	300
ZDP-1000×1000	1	2×0.4	2-5	600
ZDP-1200×1200	1.44	2×3	2-5	1200
ZDP-1500×1500	2.25	2×3	2-5	2000
ZDP-3000×3000	9	6×1.5	2-5	3000
