Conveyor Belt Multi Layer Hot Air Dryer
Five-Layer Mesh Belt Dryer Specification
Item |
Parameter |
Item Name |
BD five layer hot air dryer |
Type |
BDHD-F-20 |
Overall Dimension |
12000×1600×4000(h)mm |
Drying Chamber |
A independent hot air circulation unit in every two meter |
Transmission |
Chain Drive |
Mesh Belt Specification |
W=1600,mesh center spacing 10×16mm,Screw diameter 1.2mm,Material SUS304,;roller 12mm round steel,pitch 150mm,Material SUS304;Chain pitch 38.1mm,roller diameter 22.23mm,thickness 3mm,Material 201 |
Mesh layer |
Five layer |
Motor Power |
3kw adopt stepless variable speed motor + frequency control |
Transmission Speed Range |
0.3~5m/min,(time 30~300min) |
Fan |
DLF4.5C low noise centrifugal fan |
Fan Parameter |
4 sets,air volume 12500-6500m³/h,motor power 4kw,rpm 900 r/min,full pressure 830Pa |
Heating Source |
Steam exchanging heat,steam pressure 0.4~0.6MPa |
Heat Exchanger |
4 sets |
Steam Consumption |
300~500kg/h |
Input Power |
≤30kw |
Drying Temperature (℃) |
0~80℃,temperature tolerances ±3℃ |
Heating Mode |
Hot air circulation heating and flow through heating |
Cleaning |
Spray cleaning on line |
Control System |
PLC control,touch screen,automatic temperature control,transmission control,air volume control,video monitoring,fault display etc |
Feeding |
Automatic distribute material,evenly distribution,thickness adjustable |
Feeding Port Size |
H=4500mm,W=2500mm |
Discharging Port Size |
H=600mm,W=2500mm |
Door |
Stainless steel appearance |
Working Voltage |
380V 3 phase |
Relative Humidity(℃) |
≤85% |
Environment Temperature(℃) |
Seasonal Temperature |
Temperature Requirement |
Should be no excessive corrosive gas,no inflammable and explosive gas around |
Site requirements |
Smooth and flat cement floor |
