Industrial belt type microwave honey suckle dryer with CE

Specifications

1.type: microwave drying machine
2.dehydrating method: microwave
duction method: continuous
4.feature: conveyorized

Application scope of industrial belt type microwave honeysuckle dryer



1) Vegetable deep processing



2) Subsidiary agricultural products deep processing.



3) Herb and Flower



4) Nutlets



5)  Chemical material



6) Medical material



7) Spices



8) Powder and Particles



9) Healthy food



Main charaters of industrial advanced plant belt type  microwave honeysuckle  dryer



The device uses the microwave heating principle, the flower in the process of heating, dehydration, softening, volatile smell of grass, the activity of the purified enzyme, appearance, colour and lustre is good. Equipment design is reasonable, compact structure, reliable performance, simple operation, convenient maintenance, following are main characters of it.



1. Microwave heating speed: directly heat on the internal and external of material at the same time, do not need to preheat. While there must be a preheating process in the traditional production



2. Heating evenly: microwave drying is completed through electromagnetic waves produced by magnetron.The internal and external of material will be heated at the same time , no leaf scald , focal side, fragment and etc.



3. Less nutrition loss: material just stay in the microwave heating box for a short time, and do not need air and steam to conduct heat, therefore can maximize keep nutrients in the material.



4. Sterilization and alcoholization: therel will be probably second pollution to the material during making process. This microwave drying equipment also have sterilizing and alcoholizing function.



5. Reduce the labor intensity, improve work efficiency: this equipment could finish feeding and baiting automatically. The operator simply press the button, monitor equipment operation condition and degree of killing out. The whole production only takes 1-2 people.  While the traditonal takes 5 to 6 people.



6. Friendly environment equipment: this equipment will not create high temperature, dust and noise



Technical Features for industrial belt type microwave honeysuckle  dryer:



Model	Magnetron Frequency (MHZ)	Output  power (kw)	Microwave  leakage (mW/cm2)	Overall Dimension  (m)	Installation  Area (m)	Gross  Weight (Kg)	Capacity of  Drying (kg/h)	Capacity of  Sterilization (kg/h)
BDMD -F-P-15	2450±50	15	≤1	6.0x1.1x1.8	9.0x3.5x2.5	2000	40-75	150-180
BDMD -F-P-20	2450±50	20	≤1	7.0x1.1x1.8	10x3.5x2.5	2500	50-120	200-250
BDMD -F-P-30	2450±50	30	≤1	8.0x1.1x1.8	11x3.5x2.5	3000	65-160	300-400
BDMD -F-P-40	2450±50	40	≤1	9.0x1.1x1.8	12x3.5x2.5	3500	100-240	400-500
BDMD -F-P-50	2450±50	50	≤1	10x1.1x1.8	13x3.5x2.5	4300	120-300	500-600
BDMD -F-P-80	2450±50	80	≤1	13x1.1x1.8	15x3.5x2.5	5000	200-480	800-900
BDMD -F-P-100	2450±50	100	≤1	15x1.1x1.8	17x3.5x2.5	6000	240-600	1000-1200
