Solid CBN insert for roughing turning high Ni and Cr casting rollers
Benefits of using CBN inserts
1. Can replace grinding operations, which reduces
machining costs.
2. Dimensional stability, which is especially important in
mass production. Minimizes the amount of scrapped parts.
3. “Green” approach, due to minimized usage of coolant.
There are a few guidelines to follow in order to achieve best results and high productivity when machining hard materials:
• CBN is characterized by hardness of 4500 HV.
The high hardness of CBN enables it to machine hard materials
at high speeds and feeds.
• Successful HPT (Hard Part Turning) demands not only suitable
cutting tools, but also the right conditions, preparation
and environment.
General tech info of the CBN inserts/Cermet inserts
Drawning and technical info of the CBN inserts/Cermet inserts
| Solid CBN Insert | L | IC | S |
| RNMN 060400/RNGN 060400 | 6.35 | 6.35 | 4.76 |
| RNMN 090300/RNGN 090300 | 9.525 | 9.525 | 3.18 |
| RNMN 090400/RNGN 090400 | 9.525 | 9.525 | 4.76 |
| RNMN 120400/RNGN 120400 | 12.7 | 12.7 | 4.76 |
| RNMN 120600/RNGN 120600 | 12.7 | 12.7 | 6.35 |
| RNMN 120700/RNGN 120700 | 12.7 | 12.7 | 7.94 |
| RNMN 150700/RNGN 150700 | 15.875 | 15.875 | 7.94 |
| RNMN 160700/RNGN 160700 | 16 | 16 | 7.94 |
| RNMN 190700/RNGN 190700 | 19.05 | 19.05 | 7.94 |
| RNMN 200700/RNGN 200700 | 20 | 20 | 7.94 |
| RNMN 201000/RNGN 201000 | 20 | 20 | 10 |
| RNMN 250600/RNGN 250600 | 25.4 | 25.4 | 7.94 |
| RNMN 250700/RNGN 250700 | 25.4 | 25.4 | 7.94 |
| RNMN 251000/RNGN 251000 | 25.4 | 25.4 | 10 |
| RNMN 251200/RNGN 251200 | 25.4 | 25.4 | 12 |
Product Display of CBN inserts/Cermet inserts
