Help CenterHot CE/GS Approved Polyester Webbing Sling
Related Products
Specifications
1) International standard color:2) Low elongation;
3) Abrasion resistant;
4)100% Polyester
Detailed Product Description
Polyester Webbing sling
1) International standard color:
2) Low elongation;
3) Abrasion resistant;
4)100% Polyester
Detailed Product Descriptio
Polyester Webbing sling
1) International standard color:
2) Low elongation;
3) Abrasion resistant;
4)100% Polyester
Hot CE/GS Approved Polyester Webbing sling
Technical data:
Safety factor: 5:1, 6:1, 7:1, 8:1;
Standard: EN1492-1:2000;
Length: 1m to 100m optional, special length may be upon request;
Color: International standard;
Rated load: 0.5t to 48t;
Width: 25mm to 300mm;
Body ply: 1ply to 4 plies.
Characteristics:
- Color code, in accordance with international standard;
- Special thickness sleeves and special technical to add using life;
- Each stripe equals to 1 ton capacity, it is easy to differentiate sling capacity;
100% polyester sling has less than 3% extension at rated capacity, and will return originally length, and less than 9-12% extension at break; - Change-bearing point to add using life;
- Polyester (PES) is resistant to most mineral acids but is damaged by alkalis. Polyamide (PA) is virtually immune to the effect of alkalis; however, they are attacked by mineral acids. Polypropylene (PP) is little affected by acids or alkalis and is suitable for applications where the highest resistance to chemicals other than solvents is required;
Easy to hand; - No junctions inside;
- High resistance to abrasions;
- Utilisations without gloves or other protections;
- Small elongation;
- Perfect adhesion to the loads;
- Complete water, oil and grease immunity.
safe work load factor
Color |
WLL |
Straight |
Choker |
Parallel |
Basket hitch(T) |
|||||||||
A |
A |
A |
||||||||||||
Mode factor |
1.0 |
0.8 |
2.0 |
1.7 |
1.4 |
1.0 |
||||||||
Purple |
1.00 |
1.00 |
0.80 |
2.00 |
1.70 |
1.40 |
1.00 |
|||||||
Green |
2.00 |
2.00 |
1.60 |
4.00 |
3.40 |
2.80 |
2.00 |
|||||||
Yellow |
3.00 |
3.00 |
2.40 |
6.00 |
5.10 |
4.20 |
3.00 |
|||||||
Grey |
4.00 |
4.00 |
3.20 |
8.00 |
6.80 |
5.60 |
4.00 |
|||||||
Red |
5.00 |
5.00 |
4.00 |
10.00 |
8.50 |
7.00 |
5.00 |
|||||||
Brown |
6.00 |
6.00 |
4.80 |
12.00 |
10.20 |
8.40 |
6.00 |
|||||||
Blue |
8.00 |
8.00 |
6.40 |
16.00 |
13.60 |
11.20 |
8.00 |
|||||||
Orange |
10.00 |
10.00 |
8.00 |
20.00 |
17.00 |
14.00 |
10.00 |
|||||||
Direction for use
1)Check weight of load;
2)Check sling rated load for type of lift, angle of loading;
3)Sling shall not be twisted, tied into knots or joined by knotting;
4)Sling shall always be protected from being cut by sharp corners, sharp edges, protrusions or abrasive surfaces;
5)Balance load;
6)Maintain load control;
7)Avoid jerking the load;
