5 ton digital crane scale with wireless controller
- 1000 Piece / Pieces per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | JNDO | Model Number: | OCS-S |
Type: | Crane Scale | Power Supply: | Lead Acid 6V/7Ah | Display Type: | LED/LCD |
Rated Load: | 50t | Accuracy: | 0.2kg to 5kg |
Product Description
Specifications
5 ton digital crane scale with wireless controller1.Enhanced Type
2.American Standard rotatable hook
3.Certificate:CE;ISO90
5 ton digital crane scale with wireless controller
Description of wireless crane scale :
Wireless electronic crane scale is one kind of frequently-used weighing device and brings great convenience to people's work.Features of wireless Crane sacle :
1.30MM(1.2'')LED display with readablity
2.High quality square die casting aluminum,sturdy and durable
3.With storing function for the present, it is convenient to record weight
4.Automatic dormancy/shutdown saving energy design
5.Weight accumulation and demanding function
6.Handheld remote control with operating easily and convenience
7.With adjusting acceleation factor of gravity, suitable for all over the world
8.Display adjsting of speed and shakeproof rank, with small error and calibration by hand
9.Independent battery box design, it is easy to replace battery
1.-Multi-weighing units:
Kg, lb, N are selectable, generally kg is the default unit.
2.-Multi-function operation:
Tare;Zero;Auto zero tracking;Total;Hold; Overload warning and record, operate through remote controller ,etc functions.
3.-User-friendly design:
Cast aluminium housing for maximum protection; Large red 5 digit LED display (digit height 30mm); Battery Operated with low battery indication; Automatic turn off , power-saving function.
MODEL | Max. capacity(kg) | Min. weigh(kg) | Division(kg) | Total dispay counts(n) |
OCS-SL-2 | 2000 | 20 | 1 | 2000 |
OCS-SL-3 | 3000 | 20 | 1 | 3000 |
OCS-SL-5 | 5000 | 40 | 2 | 2500 |
OCS-SL-10 | 10000 | 100 | 5 | 3000 |
OCS-SL-15 | 15000 | 200 | 5 | 3000 |
OCS-SL-20 | 20000 | 200 | 10 | 2000 |
Standard | According to OIML class III |
Display | 30mm (1.2’’) 5digits LCD/LED |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Stable Time | ≤10seconds |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Life | ≥50 hours |
Battery Type | Fully sealed Lead-Acid battery, 6V/4.5Ah |
Adapter | DC9V/1000mA |
Operating Humidity | ≤85% RH under 20℃ |
Remote Controller Distance | Min. 15m |
Battery of Remote Controller | AAA battery, 1.5V×2 |
MODEL | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | H(mm) | N.W.(kg) |
---|---|---|---|---|---|---|---|
OCS-SL-2 | 95 | 260 | 33 | 195 | 135 | 430 | 10.5 |
OCS-SL-3 | 95 | 260 | 40 | 195 | 135 | 455 | 11.5 |
OCS-SL-5 | 120 | 325 | 50 | 240 | 165 | 535 | 17.5 |
OCS-SL-10 | 124 | 325 | 60 | 240 | 165 | 660 | 27.5 |
OCS-SL-15 | 225 | 345 | 70 | 240 | 165 | 855 | 49 |
OCS-SL-20 | 225 | 345 | 85 | 240 | 165 | 920 | 56 |
wireless crane scale Photo Show:
Delivery: 10 days after received the order
Packaging: carton or wooden industrial scale
We can provide not only amazing products,but also special ones designed at requests. We'll do our best to meet the need of customers.
