Specifications
2014 G80 Stainless steel Weld Link Chain1.Capacity from 1T to 10T
2.Competitive price
3.Accept OEM
4.Safety and durable
2014 G80 Stainless steel Weld Link Chain
G80 Stainless steel Weld Link Chain Specifications
1.CE and ISO9001
2.Competitive price
3.Delivery in Time
4.High factor of safety
5. Durable.
G80 Link Chain
lifting chain
Size:6mm to 28mm
Grade 80/ EN818-2
Black Oxidation;Zinc Plated;Self Colour;Stainless Steel
G80 Stainless steel Weld Link Chain
1.breaking load: we promise you that the tensile load reach up to Grade 80 level.
2. surface treatment: nature color/polish/oxidated black/ electronic galvanized
3. normail package: steel barrels with pallet.
4. standards: EN818-2, DIN5687-80, ASTM, NACM
|
Size dxp mm |
Width |
Approx Weight kg/m |
Working Load Limit t |
Test Load kn |
Breaking Load min. kn |
|
|
Inside min. a |
Outside max. b |
|||||
6x18 |
7.5 |
21 |
0.79 |
1.1 |
27 |
45.2 |
7x21 |
9 |
24.5 |
1.07 |
1.5 |
37 |
61.6 |
8 x 24 |
10 |
28 |
1.38 |
2 |
48 |
80.4 |
10 x 30 |
12.5 |
35 |
2.2 |
3.2 |
76 |
125 |
11 x 43 |
12.6 |
36.5 |
2.33 |
3.8 |
92 |
154 |
12 x 36 |
15 |
42 |
3.1 |
4.6 |
109 |
181 |
12.5 x 38 |
15.5 |
42.2 |
3.3 |
4.9 |
117 |
196 |
13 x39 |
16.3 |
46 |
3.8 |
5 |
128 |
214 |
14 x 42 |
18 |
49 |
4.13 |
6.3 |
150 |
250 |
14 x 50 |
17 |
48 |
4 |
6.3 |
150 |
250 |
15 x 46 |
20 |
52 |
5.17 |
7 |
168 |
280 |
16 x 48 |
20 |
56 |
5.63 |
8 |
192 |
320 |
16 x 49 |
24.5 |
59.5 |
5.71 |
8 |
192 |
320 |
16 x 64 |
23.9 |
58.9 |
5.11 |
8 |
192 |
320 |
18 x 54 |
23 |
63 |
6.85 |
10 |
246 |
410 |
18 x 64 |
21 |
60 |
6.6 |
10 |
246 |
410 |
19 x 57 |
23.7 |
63.2 |
7.7 |
11.3 |
270 |
450 |
20 x 60 |
25 |
70 |
8.6 |
12.5 |
300 |
500 |
22 x65 |
28 |
74.2 |
10.7 |
15.3 |
366 |
610 |
22 x66 |
28 |
77 |
10.2 |
15.3 |
366 |
610 |
22 x 86 |
26 |
74 |
9.5 |
15.3 |
366 |
610 |
24 x72 |
32 |
82 |
12.78 |
18 |
432 |
720 |
24 x 86 |
28 |
79 |
11.6 |
18 |
432 |
720 |
26 x 78 |
35 |
91 |
14.87 |
21.3 |
510 |
850 |
26 x 92 |
30 |
86 |
13.7 |
21.3 |
510 |
850 |
30 x 90 |
38 |
105 |
19.6 |
28.3 |
678 |
1130 |
30 x108 |
34 |
98 |
18 |
28.3 |
678 |
1130 |
32 x 96 |
40 |
106 |
22.29 |
32.2 |
772 |
1286 |
34 x126 |
38 |
109 |
22.7 |
36.3 |
870 |
1450 |
34 x102 |
46.5 |
121.5 |
25.5 |
36.3 |
870 |
1450 |
36 X108 |
49.5 |
128.5 |
31 |
40.7 |
978 |
1630 |
38 x137 |
42 |
121 |
29 |
45.3 |
1086 |
1810 |
38 x 114 |
52 |
136 |
32 |
45.3 |
1086 |
1810 |
42 x 126 |
55.5 |
144.5 |
38.6 |
55.4 |
1332 |
2200 |
We can provide not only amazing products,but also special ones designed at requests.We'll do our best to meet the need of customers.
Welcome to JNDO
Your success is our business
