Diamond Oil Drilling Bit

Henan Zhongmei Drill Tool Co., Ltd.
Diamond Oil Drilling Bit thumbnail-1
Diamond Oil Drilling Bit photo-1
US$ 1 - 10,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
ZM
Model Number:
all type
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name ZM
Model Number all type
Type Other, drill bit
Material Cobalt Steel Alloys
Use Other, well drilling,mining drilling

Specifications



1.manufacturer of rock drill bit,button bit,tricone bit,tricone drill bit
2.long service life low drilling cost
3.ISO9001



  diamond oil drilling bit  :



1. Metal-face sealed bearing Tricone Bit
Cutting StructureThe durability of premium tungsten carbide inserts is improved with new formulas and new techniques for insert bit.

Gauge StructureMultiple gauge protection with gauge trimmers on heel and gauge inserts on the gauge surface of the cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.
Sealed Bearing Structure    1.Abrasion resistance and seizure resistance of the bearing are improved and suitable for high rotary speed.
     2.The advanced metal seal package will improve the reliability and durability of bearing seal.
Main Type Available Size: 6",6 1/2",7 1/2",8 1/2",9 1/2",9 5/8",9 7/8",12 1/4",17 1/2", etc.
  IADC Code:4-- Series, 5-- Series, 6-- Series,etc.

2. Elastomer sealed bearing Tricone Bit
Cutting StructureThe durability of premium tungsten carbide insert is improved with new formulas and new techniques for insert bit.

Gauge Structure Multiple gauge protection with gauge trimmers on the heel of cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability and bearing life.
Sealed Bearing Structure1.Abrasion resistance and seizure resistance of the bearing are improved.
     2.Premium O-ring, Optimal seal compression and curved seal structure can enhance the seal performance.
Main Type AvailableSize: 5 7/8",6",6 1/2",7 1/2",7 7/8",8 1/2",9 1/2",9 5/8",9 7/8",12 1/4",14 3/4",17 1/2", etc.
  IADC Code:4-- Series, 5-- Series, 6-- Series,etc.

3. Air Cooling Roller Bearing Tricone Bit
Cutting Structure   The durability of premium tungsten carbide insert is improved with new formulas and new techniques and new techniques.

Gauge Structure   Gauge protection with gauge inserts on the gauge surface of the cone, tungsten carbide inserts and hardfacing on the shirttail increases gauge holding capability.
Sealed Bearing Structure    Air cooling roller bearing package. Balls lock the conewhich reduces the probability of cone-dropping to minimum.
Main Type AvailableSize: 8 1/2",9 1/2",9 5/8",9 7/8",10 5/8",12 1/4", etc.
  IADC Code:5-- Series,6-- Series,7--

4,Non-Sealed Roller Bearing Bit
Cutting StructureThe durability of premium tungsten carbide inserts is improved with new formulas and new techniques for insert bit.

Bearing StructureNon-sealed roller bearing. Drilling fluid can enter the bearing directly for cooling; Balls lock the cone which reduces the probability of cone Cdropping to minimum.
Main Type AvailableSize: 2 3/8",3",3 5/8:",3 7/8",4",4 1/2",4 5/8",4 3/4",6",6 1/2",7 1/2",8 1/2",9 1/2",9 5/8",9 7/8",12 1/4",15",15 1/2",17 1/2", etc.
  IADC Code:5-- Series,6-- Series

 diamond oil drilling bit
