B Series/N Series Electroplated Reamer Superior Quality

B Series/N Series Electroplated Reamer Superior Quality thumbnail-1
B Series/N Series Electroplated Reamer Superior Quality photo-1
US$ 30 - 200 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
ZM
Model Number:
Types
Contact Supplier Request Quote Chat Now
Henan Zhongmei Drill Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name ZM
Model Number Types
Type Center Drill Bit
Material Diamond
Use Masonry Drilling

Specifications

Reaming shell/Diamond Reaming shell/PCD reaming shell/TC reaming shell/surface set reaming shell with A series,B series,N series,H series,P series,T2,T6

Reaming shell(reamer)

Reaming shells (with double pads or three pads) are suitable to use in all formation conditions ranging from broken and abrasive to consolidated and non-abrasive. As this kind of reaming shell is physically longer than the standard type, it is necessary to use an appropriate inner tube extension in order to compensate for the difference in overall reaming shell length.

Combined high quality and design make our reaming shells the best in the industry. With several different types, we've got you covered no matter what your requirements are.

Core bits

Reaming Shell

Size

O.D (mm)

I.D(mm)

Size

Set Diameter(mm)

A series

47.75/47.50

27.10/26.85

A series

48.13/47.88

AWG(AX)

47.75/47.50

30.23/29.97

AWG(AX)

48.13/47.88

AWM

47.75/47.50

30.23/29.97

AWM

48.13/47.88

B series

59.69/59.44

36.52/36.27

B series

60.07/59.82

B series3

59.69/59.44

33.65/33.40

B series3

60.07/59.82

BWG(BX)

59.69/59.44

42.16/41.91

BWG(BX)

60.07/59.82

BWM

59.69/59.44

42.16/41.91

BWM

60.07/59.82

N series

75.44/75.19

47.75/47.50

N series

75.82/75.57

N series 2

75.44/75.19

50.80/50.55

N series2

75.82/75.57

N series3/N seriesTT

75.44/75.19

45.21/44.96

N series3/N seriesTT

75.82/75.57

NWG(NX)

75.44/75.19

54.86/54.61

NWG(NX)

75.82/75.57

NWM

75.44/75.19

54.86/84.61

NWM

75.82/75.57

NMLC

75.44/75.19

52.12/51.87

NMLC

75.82/75.57

H series

95.76/95.38

63.63/63.38

H series

96.27/95.89

H series3/H seriesTT

95.76/95.38

61.24/60.99

H series3/H seriesTT

---

HWG(HX)

98.98/98.60

76.33/76.08

HWG(HX)

99.36/99.11

HMLC

98.98/98.96

63.63/63.38

HMLC

98.20/97.80

P series

122.30/121.80

85.09/84.84

P series

122.81/122.43

P series3

122.30/121.80

83.18/82.93

P series3

122.81/122.43

T2-76

76.12/75.87

61.82/61.57

T2-76

76.50/76.20

T2-101

101.12/100.80

83.82/83.57

T2-101

101.50/101.20



B series/N series electroplated reamer superior quality

Please feel free to contact with us if you need detailed speicifations or catalog.

B series/N series electroplated reamer superior qualityB series/N series electroplated reamer superior qualityB series/N series electroplated reamer superior quality
