INTRODUCTION
Henan zhongmei can supply all kinds of PDC Coring and non-coring bits, PDC sintering matrix bits and PDC anchoring bits. PDC bit can be widely used in the fields of geological exploration, coal mining, water conservancy and hydropower, construction of road and railway.
We also can design PDC bits according to customer requirements, such as different geological condition, special strata and so on.
THEORY
PDC(polycrystalline diamond compact) drill bit is a new product after the hot-pressed and electroplated drill bit recent years.With special hith-frequency weldin techniques.PDC of high wear resistant si welded to the body as cutting edges.PDC bit is mainly used for geological prospecting,coal exploration,water conservancy and power engineering,etc.
FEATURE
1. It has a super long life. The grinding/consumption ratio of PDC is 20-40 times that of tungsten carbide bit and 10 times that of diamond bit.
2. It had high drilling speed.
3. It can be operated with low pressure and low speed.
4. It has a good gage protection.
5. It can be used widely, more suitable for drilling in the stratum with formation<7
6. It has a low cost
APPLICATION
PDC Coring bit-Cobblestons-specific PDC Bit is a kind of pipe-shaped bit with PDC which can get the coring. It is used for geological exploration, coal mining. water canservancy and hydropower, road construction, railway, bridge and building.
SPECIFICATION
Specifications Diameter(mm) | Size | Cutting Wings | Screw | Rock formation | |||
Outer Dia(mm) | Inner Dia(mm) | Height(mm) | Wing Quantity | PDC Quantity | |||
75 | 75 | 53 | 150 | 5/6 | 5/6 | Square | F<7medium hard( Soft rock, coal seam drilling and grouting) |
94 | 94 | 69 | 170 | 6/8 | 6/8 | ||
113 | 113 | 88 | 195 | 8/10 | 8/10 | ||
133 | 133 | 108 | 220 | 10/12 | 10/12 | ||
153 | 153 | 128 | 245 | 12 | 12 | ||
We are also can design and manufacture of various non-standard drill tools.
If you have any questions, please don't hesitate to contact us.
