WLNQ WLHQ WLPQ NW NX Diamond Core Drill Bit

WLNQ WLHQ WLPQ NW NX Diamond Core Drill Bit thumbnail-1
WLNQ WLHQ WLPQ NW NX Diamond Core Drill Bit photo-1
US$ 60 - 325 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
ZM
Model Number:
all type
Contact Supplier Request Quote Chat Now
Henan Zhongmei Drill Tool Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Ningbo shanghai tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name ZM
Model Number all type
Type Core Drill Bit
Material Diamond
Use Other, geological drilling,well drilling

Specifications

diamond core drill bit
1.surface-set/impregnated diamond bits
2.Q serie
3.high quality,delivery on time
4.ISO9001:2008

WLNQ WLHQ WLPQ NW NX  diamond core drill bit

product introduction:



The impregnated diamond bits are the most commonly useful bits in the mineral exploration industry, as they have the widest range of application. The carefully selected grades of high quality synthetic diamond are distributed in the depth of impregnated bit's matrix series. The matrix layer of the ZM contains a uniform distribution of these crystals that are embedded in a powdered metal bond.

The matrix of our impregnated bits is designed to expose new diamonds to the bits' cutting face as wear occurs. Fast penetration rate is maintained as a result of this action.

Our impregnated bits are manufactured to give optimum penetration rates and bit life, which is required to keep the cost of diamond drilling to a minimum.

Size Available as followings:
AQ, BQ, PQ/AQTK, BQTK, BQ3, NQ2, NQ3, NQTT, HQ3, HQTT, PQ3, PQTT
T2 series: T2 46, T2 56, T2 66, T2 76, T2 86, T2 101
T6 series: T6 76, T6 86, T6 101, T6 116, T6 131, T6 146, T6S 101, T6S 116
T series: T36, T46, T56, T66, T76, T86
Z series: Z46, Z56, Z66, Z76, Z86, Z101, Z116, Z131, Z146
B series: B36, B46, B56, B66, B76, B86, B101, B116, B131, B146
WF series: HWF, PWF, SWF, UWF, ZWF
WT series: RWT, EWT, AWT, BWT, NWT, HWT
WM series: EWM, AWM, BWM, NWM, HWM
WG series: EWG, AWG, BWG, NWG, HWG
Others: NMLC, HMLC, LTK48, LTK60, BGM, NGM, ADBG, TBW, TNW, ATW, BTW, NTW, NXD3, AX, NX, NXC, AXT, T6H, 4 9/16, NWD4, 412F, SK6L146, TT46, TB56, TS116, CHD101.



Non-standard also can be made as your demand.



Size



Outside Diameter

Inside Diameter

inch

mm

inch

mm

AQ

  1.880/1.870

 47.75/47.50

  1.607/1.057

  27.10/26.85

BQ

2.350/2.340

59.69/59.44

1.438/1.428

36.52/36.27

NQ

2.970/2.960

75.44/75.19

1.880/1.870

47.75/47.50

HQ

3.770/3.755

95.76/95.38

2.505/2.495

63.63/63.38

PQ

4.815/4.795

122.30/121.80

3.350/3.340



other related product:

we also produce reamer shell,casing shoes,core barrel,drill rod,casing,overshot,wrenches,fishing tools and other diamond tool accessories



product picture:

 WLNQ WLHQ WLPQ NW NX diamond core drill bit



WLNQ WLHQ WLPQ NW NX diamond core drill bit
certificate:

WLNQ WLHQ WLPQ NW NX diamond core drill bit
