Chisel Bits/chisel Bit/chisel Drill Bits/taper Chisel Bit/rock Chisel Bit

Henan Zhongmei Drill Tool Co., Ltd.
Chisel Bits/chisel Bit/chisel Drill Bits/taper Chisel Bit/rock Chisel Bit thumbnail-1
Chisel Bits/chisel Bit/chisel Drill Bits/taper Chisel Bit/rock Chisel Bit photo-1
US$ 1,000 - 5,000 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
ZM
Model Number:
all
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name ZM
Model Number all
Type Other, Paring Chisel, Drill Bit
Use Other, Other, Coal Mining

Specifications

Item:chisel bits
Dia of chisel bit:20-80mm
tip size:12x6, 14x8,13x8,16x10,26x16x10
Weight: 0.1-1.4kg
Rock class:10-14

chisel bits/chisel bit/chisel drill bits/taper chisel bit/rock chisel bit/tapered chisel bit
Item:Dia of Bit:20-80mm
tip size:12x6, 14x8,13x8,16x10,26x16x10
Weight: 0.1-1.4kgs
Rock class:10-14

Chisel bits:with the characteristic of high streength,long life in usage and good prices

Materials: Steel body, made by material 42CrMo
Suitable tungsten-carbide grade are selected according to the work project
Can guarantee good performance when working.Our construction tools include auger bits,rotary bits,flat bits etc,which are widly used in the field of railway,highwary,mining,water and electricity construction,water conservancy,and municipal works.

chisel bits/chisel bit/chisel drill bits/taper chisel bit/rock chisel bit
Threaded/Tapered (taper 7, 12degree) chisel/cross bits are mostly used for hand-held rock drill. We make them from alloy steel by forging and select suitable tungsten carbide insert as per customers requests in accordance with their local rock conditions,such as , limestone,marble, granite etc.

The chisel bit  made from grade hard alloy and special steel, generally matched with the light-duty rock drill,  drilling the hole within diameter of 50mm



It is widely used in metallurgy mine, geological exploration, water conservancy construction, electricity, traffic, tunnel, quarry, national defence stone project.



Bit Diameter



Carbide

Taper

Water

Part No.

mm

inch

Width*Height

Hole

30

1  3/16

8—10*13.5—15

7

2

CH130-722

32

1 17/64

8—10*13.5—15

7

2

CH 132-722

34

1 11/32

8—10*13.5—15

7

2

CH 134-722

36

1 27/64

8—10*13.5—15

7

2

CH 136-722

38

1 1/2

8—10*13.5—15

7

2

CH 138-723

40

1 37/64

8—10*13.5—15

7

2

CH 140-723

42

1 21/32

8—10*13.5—15

7

2

CH 142-723

20

2  5/32

6*12

4

1

CH 220-415

22

5  5/64

6*12

4

1

CH 222-415

24

1  5/16

8*13

4

2

CH 224-415

26

1  1/32

8—10*13.5—15

4

2

CH 226-415

28

1  7/64

8—10*13.5—15

6

2

CH 228-722

30

1  3/16

8—10*13.5—15

7

2

CH 230-722

32

1 17/64

8—10*13.5—15

7

2

CH 232-722

34

1 11/32

8—10*13.5—15

7

2

CH 234-722

36

1 27/64

8—10*13.5—15

7

2

CH 236-723

38

1 1/2

8—10*13.5—15

7

2

CH 238-723

40

1 37/64

8—10*13.5—15

7

2

CH 240-723

42

1 21/32

8—10*13.5—15

7

2

CH 242-723

50

1 31/32

8—10*13.5—15

7

2

CH 250-725

56

2 13/64

8—10*13.5—15

7

2

CH 256-725

60

2 23/64

8—10*13.5—15

7

2

CH 260-725
