Help CenterPP Prestressed Plastic Corrugated Pipe Production Line
Related Products
-
PE Carbon Spiral Reinforcing Pipe Production Line.US$ 3,000 - 80,000MOQ: 1 Set -
HDPE/PP/PVC Double Wall Corrugated Pipe Extrusion LineUS$ 3,000 - 80,000MOQ: 1 Set
-
PE/PP/PVC Single Wall Corrugated Pipe Extrusion LineUS$ 3,000 - 80,000MOQ: 1 Set
-
SWP Series Plastic CrusherUS$ 1,000 - 50,000MOQ: 1 Set
-
Pre-sressed Singal Wall Plastic Machine of Corrugated Pipe Production LineUS$ 1,000 - 50,000MOQ: 1 Set
Specifications
This kind of corrugated pipe is mainly used for underground water drainage system..
As a new type of holed mateial, prestressed single wall corrugated pipe has many advantages compared with metallic corrugated pipe.
It is acid resistant, alkali resistant, it has good sealing property, there is no seepage for water or page, its rigidity is rather high. Its frictional coefficient is small. It is ageing proof, electric erosion proof, it has good soft flexibility. It can not be easily broken by a diging bar. It is convenient for connection in construction.
So it has overcome all shortcomings of traditional metallic corrugated pipes. Such kinds of pipes are originally imported from oversea with rather high price and long time delivery.
Facing such status, Zhangjiagang saiou machinery Co.,Ltd has positively absorbed and introduced technique of foreign equipment and depend on relative research institutes and developed production line of chiefly HDPE prestressed single wall corrugated pipe, the specification ranges from 50-160mm.
This item has filled national gap. This will undoubtly facilitate application of prestressed single wall corrugated pipe. It will also bring a lot of profit for producers of relative finished products.
Composition of the production line |
Model |
Motor power(kw) |
Weight(kg) |
Quantity |
Characteristics |
Single screw extruder |
SJ65/28, SJ90/28 |
22,25 |
2500,3000 |
1 |
High efficient extruding |
Machine die head |
|
|
|
|
Complete cooling system |
Pipe forming machine |
BW-I,BW-II,BW-III |
2.2,4,5.5 |
19000 |
1 |
Specification:50-60mm |
Pipe cutting machine |
STYF-160 |
2.2 |
4500 |
1 |
Cutting range: 20-160mm |
Mould cooler |
SML-7F |
10MP |
420 |
1 |
Rapid cooling mould |
Hopper drier |
STG-U40 |
2.6 |
50 |
1 |
|
Automatic feeding machine |
ZJ200 |
1.1 |
50 |
1 |
Automatic feeding |
Plastic mixing machine |
SH50 |
1.1 |
80 |
1 |
Mixing&colourin raw material |
Plastic crushing machine |
SWP400 |
18.3 |
980 |
1 |
Crush plastic pipes directly. |
Flat pipe production line
Composition of the production line |
Model |
Motor power(kw) |
Weight(kg) |
Quantity |
Characteristics |
Single screw extruder |
SJ65/28 |
22 |
2500 |
1 |
High efficient extruding |
Machine die head |
|
|
|
|
Complete cooling system |
Pipe forming machine |
BW-I |
2.2 |
3000 |
1 |
Specification:50-60mm |
Spray cooling tank |
6meter |
Water pump power 4kw |
100 |
1 |
Strong spray cooling system |
Pipe cutting machine |
STYF-100 |
2.2 |
200 |
1 |
Micro computer control |
Mould cooler |
SML-3F |
3MP |
180 |
1 |
Rapid cooling mould |
Hopper drier |
STG-U40 |
2.6 |
50 |
1 |
|
Automatic feeding machine |
ZJ200 |
1.1 |
50 |
1 |
Automatic feeding |
Plastic mixing machine |
SH50 |
1.1 |
80 |
1 |
Mixing&colourin raw material |
Plastic crushing machine |
SWP400 |
18.3 |
980 |
1 |
Crush plastic pipes directly. |
