Specifications
PVC Pipe Extrusion Line1.Automatic Temperature Control
2.DC Motor Drive
3.Eurotherm Convertor
4.Stable Output
Features of the linePVC Pipe Extrusion Line
- PVC Pipe Extrusion Line conical twin screw extruder and the traction machineemploy famous brand AC frequency control device .The vacuum pump and the electric motor are of superior quality .Four types of traction machine are avaliable : two ,three,four and six caterpillar traction .
- Two types of cutting-saw blade or planet cutting.
- Lenth-setting apparatus can be attached to the traction machine .
- Optional devices: pipe end expanding device,spiral muffler tube making unit and core foaming tube making unit as required .
- Traction machine with caterpillars for hauling PVC pipe of large diameter.
PVC Pipe Extrusion LineFeatures
1.Twin Screw Extruder
2.Special Designed Mould
3.Automatic PLC Control
4.Special PVC Cutting Blade
5.Eurotherm Speed Changer
6.Schneider Electrical Parts
PVC Pipe Extrusion Line Main Parameter of Line
Model |
Pipe dia(mm) |
Extruder |
Speed of line (m/min) |
Max. output (kg/h) |
Total power(kw) |
Dimension LxWxH |
K63 |
16-63 |
51/105 |
1-12 |
120 |
65 |
30x1.8x2m |
K160 |
75-160 |
65/132 |
0.5-5 |
260 |
105 |
36x2x2m |
K250 |
90-250 |
80/156 |
1-3.6 |
400 |
145 |
37x2x2m |
K400 |
200-500 |
92/188 |
0.2-2 |
600 |
210 |
42x2.5x2.5m |
K630 |
400-630 |
92/188 |
0.08-0.8 |
700 |
245 |
48x2.5x2.5m |
K800 |
500-800 |
92/188 |
0.04-0.3 |
700 |
260 |
54x2.5x2.5m |
Note:we reserve all the right to change any of the specification data without notice.
PVC pipe is used for:
Drain-waste-vent (DWV)
SEWERS
WATER MAINS
WATER SERVICE LINES
IRRIGATION CONDUIT
VARIOUS INDUSTRIAL INSTALLATIONS..
PVC pipe dimeter range:16-630mm
