Plant Photosynthesis Meter

Application

The equipment is specially designed for plant physiology experiment teaching, and can also meet the undergraduate course teaching and advanced plant physiology experiment course, significantly improve the teaching quality of theory and experiment.In biology, the agronomy, horticulture, forestry, insects, microorganisms, animals, and many other professional experiments course have wide prospect of use.
The instrument can be used to measure the gas concentration of CO2, air temperature and humidity, plant leaf temperature, light intensity, gas flow rate, etc.

Features:

1. The measurement functions
• measuring CO2 concentration in the air, humidity, temperature, leaf temperature
• measurement in the gas flow in the gas path
With open and closed two measuring ways
2. Computing functions automatically calculate the following parameters:
• photosynthetic rate (breathing)
Leaf transpiration rate
• intercellular CO2 concentration
Stomatal conductance,
3. The display
The CO2 density, air temperature, humidity, air temperature, leaf
• timing display
The photon flux density values
4. Storage transmission function
• can be stored and data transmission used in the measurement and calculation
5. Mobile capabilities
Desktop and portable
6. Power supply function
The ac power adapter or rechargeable battery
• low voltage alarm

Specification

1. The CO2 sensor:
Category: the spread of infrared analyzer
Measuring range: 0 ~ 1500 PPM
Resolution: 1 PPM
2. The humidity sensor
Category: humidity-sensitive capacitance
Measuring range: 0 ~ 100% RH
Resolution: 0.1%
3. The temperature sensor
Category: thermistor
Measuring range: 0 ~ 50 ℃
Resolution: 0.1 ℃
4. Light quantum sensor
Category: silicon photocell with modified filter
Measuring range: 0 ~ 2000 mu mol/m2, s
Resolution: 1 mu mol/m2, s
Spectral range: 400 ~ 700 nm
5. Flow meter
Category: micro electron flow quantum
Measuring range: 0.0 ~ 1.0 / min
Resolution: 0.1 L/min
6. Leaf temperature sensors:
Category: thermocouple
Measuring range: 0 ~ 50 ℃
Resolution: 0.1 ℃
7. The main machine
Monitor: eight independent big liquid crystal display subtitles
Power supply: DC7.2 V rechargeable battery;An external 220 vac power adapter
Data storage: can store up to a maximum of 1024 set of measurement data
Weight: 3.0 kg net
8. Leaves room:
Ⅲ type (65 x 10 mm)
