Help CenterMetal Coating Equipment (aluminum Plate and Steel)
Related Products
Specifications
1. Full automatic control2. High productivity
3. Small area occupation
4. Low energy consumption
5. Less powder
1. Full automatic control
2. High productivity
3. Small area occupation
4. Low energy consumption
5. Less powder
Production technology process
NO |
Process name |
The temperature(°C) |
The processing time (min) |
Handling |
1 |
Hang up the artifacts |
|
|
|
2 |
Pickling |
50-60 |
1 |
Spray |
3 |
Pickling |
50-60 |
2 |
Spray |
4 |
Washing |
RT |
1 |
Spray |
5 |
Washing |
RT |
1 |
Spray |
6 |
Surface conditioning |
RT |
1 |
Spray |
7 |
Phosphating |
50-55 |
3 |
Spray |
8 |
Washing |
RT |
1 |
Spray |
9 |
Washing |
RT |
1 |
Spray |
10 |
Drying |
110-140(adjustable) |
10-20 |
Hot air circulation |
11 |
Spraying |
RT |
According to the workpiece |
Automatic spraying |
12 |
Curing |
180-200(adjustable) |
20-25 |
Hot air circulation |
13 |
Spraying workpiece completed |
RT |
According to the production speed |
Natural drying |
1) Pretreatment: Dipping pretreatment with overhead crane, or fully automatic spraying pretreatment
2) Conveying system: closed-circuit conveyor, power and free conveyor, multi-track conveyor, and so on
3) Oven: batch oven, combination oven, bridge curing oven, tunnel oven
4) Powder coating booth: stainless steel booth or coated steel booth
5) Powder recycling facility,cyclone pulse recovery system
cyclone pulse recovery system or pulse recovery system
6) Control system: PLC control, with or without touch screen
7) Spray gun and reciprocator
1) Pretreatment: Dipping pretreatment with overhead crane, or fully automatic spraying pretreatment
2) Conveying system: closed-circuit conveyor, power and free conveyor, multi-track conveyor, and so on
3) Oven: batch oven, combination oven, bridge curing oven, tunnel oven
4) Powder coating booth: stainless steel booth or coated steelbooth
5) Powder recycling facility,cyclone pulse recovery system
cyclone pulse recovery system or pulse recovery system
6) Control system: PLC control, with or without touch screen
7) Spray gun and reciprocator
1) Pretreatment: Dipping pretreatment with overhead crane, or fully automatic spraying pretreatment
2) Conveying system: closed-circuit conveyor, power and free conveyor, multi-track conveyor, and so on
3) Oven: batch oven, combination oven, bridge curing oven, tunnel oven
4) Powder coating booth: stainless steel booth or coated steel booth
5) Powder recycling facility,cyclone pulse recovery system
cyclone pulse recovery system or pulse recovery system
6) Control system: PLC control, with or without touch screen
7) Spray gun and reciprocator
