Specifications
1. A good coating production line2. High productivity
3. Small area occupation
4. Low energy consumption
5. Less powder
spraying coating equipment
1.
| 1 | Process mode: spray type | Spray type |
2 |
The bulk material |
Plate SUS304 # t1.5 mm |
3 |
The spray materials |
PVC, pp |
4 |
The liquid trough |
plate SUS304 # t1.5 in mm |
5 |
Pump |
Corrosion resistant power pcs |
Pretreatment: Remove the workpiece the foreign body,such scale cinder, rusty spot, grease, etc, Provide good base suitable for coating requirements, Phosphating ensure coating has a good anticorrosive and decorative performance.
2.
1 |
Insulation board |
The furnace plate thickness 100mm The inner plate SPGt1.omm The outer color plate t0.7mm Heat preservation cotton specification 80kg |
2 |
Chassis |
10#Square steel pipe |
3 |
Heating power |
100000 calories burn machine 1pes |
4 |
Heating chamber |
100000 calories burn machine 1pes |
5 |
warm air machine |
5HP |
Drying oven: In the drying furnace, the workpiece surface water and water of crystallization and drying, required to meet the requirements of the coating
3
1 |
The chamber body plate |
SPGt1.5mm Hydraulic molding |
2 |
Chassis |
5# Channel steel |
3 |
Recycling filter |
Diameter of the325*L900mm |
4 |
Exhaust fan |
20HP |
5 |
Pulse control meter |
CMOS |
6 |
Reciprocating engine |
Travel back and forth 1.5m |
7 |
Spray gun |
Automatic and manual (According to the customer workpiece) |
Spraying:The workpiece into the spray chamber to wake with electrostatic powder spraying operations
4
1 |
Insulation board |
The furnace plate thickness 100mm The inner panels SPGt1.0mm The outercolor plate t0.7mm Heat preservation cotton specification 80kg
|
2 |
Chassis |
10# Square steel pipe |
3 |
Heating power |
300000 calories burn machine 1pes |
4 |
Heating chambe |
he furnace plate 100mm |
Curing oven: In the curing oven, the workpiece, communication molten coating on the surface and curing.
5 Control system, conveyor line
(1) The mode of transportation: Suspension transport
(2) Bear the weight: According to the customer request
(3) Drive power: Synchronous operation
(4) The running speed: Adjustable frequency
(5) Trackn: Wear resistant manganese steel
(6) Safety device: Automatic clutch protection Overload protection
