Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > HF856A Efficiency Rotary Drilling Rig Rotary CE&ISO Certification Used in Foundation Constructure
HF856A Efficiency Rotary Drilling Rig Rotary CE&ISO Certification Used in Foundation Constructure
US$ 12,100 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai/Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HF856A Efficiency Rotary Drilling Rig Rotary CE&ISO Certification Max Pile Depth 56m Engineer Oversea Service okUS$ 12,100 - 15,000MOQ: 1 Set -
HF856A Efficiency Rotary Drilling Rig Rotary With ISO & CE Certification Engineers Oversea Service okUS$ 12,100 - 15,000MOQ: 1 Set
-
HF856A Rotary Piling Rig With ISO & CE Certification for Road Bridge Foundation ConstructionUS$ 12,100 - 15,000MOQ: 1 Set
-
HF525 Hydraulic Small Rotary Piling Rig for Sale Max Piling Depth 25m Maxpiling Diameter 1400mmUS$ 12,100 - 15,000MOQ: 1 Set
-
360-degree Rotation Energy-saving Drilling Machine,11m Depth Pile Drilling Rig, HF360 Piling Drilling RigNegotiableMOQ: 1 Set
Condition
New
CNC or Not
Normal
Place of Origin
Henan, China
Brand Name
HF
Model Number
HF856A
Voltage
380V
Power(W)
112KW
Dimension(L*W*H)
Working dimension 18050x7297x3200mm
Weight
38000KGS
Certification
ISO 9001 : 2000
After-sales Service Provided
Engineers available to service machinery overseas
HF856A efficiency rotary drilling rig rotary drilling machine for piling foundation
Features and advantages:
1. Adopting telescopic mast structure which owns simple structure and kades transportation more convenient.
2. The +- shape axle ned structure is used to fax boom and link arm, boom can adjust around and control the arm,guarantee vertical on rough place.
3. Triangular structure between link arm and amplitude clinder increases the machine stability.
Specification:
| Drilling diameter | 600-1600mm |
| Max drilling depth | 56m |
| Working dimension | 18050x3200x7297mm |
| Transport dimension | 14727x3200x3325mm |
| Machine Weight | 38000KGS |
| Engine model | B5.9-C Cummins (USA) |
| Engine power | 112KW |
| Engine Type | Turocharged direct-injection |
| Rotary drive | Max.torque 80 KN.M |
| Rotation speed | 1-22 RPM |
| Crowd clinder Max.push | 150 KN |
| Max.pull | 100 KN |
| Max.stroke | 2000mm |
| Main winch Max.line pull | 120KN |
| Max.line speed | 70m/min |
| Rope diameter | 24mm |
| Auxiliary winch Max.line pull | 60KN |
| Max.line speed | 50m/min |
| Rope diameter | 18mm |
| Mast inclination Free adjustment forward/backward | 0-93° |
| Free adjustment left/right | +/-3° |
| Electronic management system On car printer | Available |
| Long distance monitor system | Available |
| Drilling record system | Availalble |
| Chassis modality | Customizable |
| Max reavel speed | 2.0km/h |
| Min ground clearance | 500mm |
| Track width | 800mm |
| Hydraulic system pressure | 300bar |
| If any not satisfied | Customizable |
