Hot Sale!!! Oil Well Drilling Hook
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
HF
Model Number:
Customized
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Latest High Quality Drilling Rig HookNegotiableMOQ: 1 Set -
Oil Drilling Rig API 8C Traveling BlockNegotiableMOQ: 1 Set
-
API Standard Spec 8C Traveling Blocks Made In ChinaNegotiableMOQ: 1 Set
-
2016 API Traveling Block and Hook Used on Oil and Gas Well Drilling RigsNegotiableMOQ: 1 Set
-
Traveling Block And Hook Forging Standard API 8C For Oil Well Drilling Rig EquipmentNegotiableMOQ: 1 Set
Place of Origin
Henan, China
Brand Name
HF
Model Number
Customized
Type
Other, Hook, High Quality Hook
Machine Type
Drilling Tool
Certification
Other, CE , ISO
Material
Other, customized
Processing Type
Other, customized
Use
Other, oil drilling rig
Hot sale!!! oil well drilling Hook
Specifications
Equipped with snubber assembly, to protect drill pipe sub when screwing off.
Bearing safety device
Feature
In accordance with the standard of API.
Especially built-in hollow with good hydro bump-absorbing capability.
The major hook has double safety devices.
The main components of the hook adopt high tense alloy and get through non-destructive testing.
Ambient temperature:-20°C~55°C
-45°C~40°C
Technical Parameters
|
Model No.
|
DG225 | DG315 | DG450 | DG675 |
|
The max.hook load(KN)
|
2250 | 3150 | 4500 | 6750 |
|
Spring travel mm(in)
|
180(7) | 200(8) | 200(8) | 220(8 5/8) |
| Major-hook opening mm(in) | 190(7 1/2) | 220(8 5/8) | 220(8 5/8) | 234(9 1/4) |
|
Overall Dim.mm (Length*Width*Hight)
|
2548 | 2960 | 2960 | 3705 |
| 780 | 890 | 890 | 1210 | |
| 750 | 830 | 880 | 930 | |
|
Weight (kg) |
2180 | 3410 | 3500 | 7065 |
