Hf Down The Hole DTH Rock Drill Bit

Hf Down The Hole DTH Rock Drill Bit thumbnail-1
Hf Down The Hole DTH Rock Drill Bit thumbnail-2
Hf Down The Hole DTH Rock Drill Bit thumbnail-3
Hf Down The Hole DTH Rock Drill Bit thumbnail-4
Hf Down The Hole DTH Rock Drill Bit thumbnail-5
Hf Down The Hole DTH Rock Drill Bit thumbnail-6
Hf Down The Hole DTH Rock Drill Bit photo-1
Hf Down The Hole DTH Rock Drill Bit photo-2
Hf Down The Hole DTH Rock Drill Bit photo-3
Hf Down The Hole DTH Rock Drill Bit photo-4
Hf Down The Hole DTH Rock Drill Bit photo-5
Hf Down The Hole DTH Rock Drill Bit photo-6
US$ 30 - 3,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Hanfa
Model Number:
82-511mm
Contact Supplier Request Quote Chat Now
Zhengzhou Han Fa Imp & Exp Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Hanfa
Model Number 82-511mm
Type Drill Bit
Machine Type Drilling Tool
Certification AISI
Material Carbide
Processing Type Forging
Use Well Drilling

Hf Down The Hole DTH Rock Drill Bit

Hf Down The Hole DTH Rock Drill Bit

Type and Technical Specification



ype Number of
 Air hole 		DIa.(mm) Weight(kg) Gauge Button Front Button Matching DTH Hammer
GL4.5-115 2 115-118 6.4 7×14 6×12 GL4.5
GL4.5-120 2 120-123 7 7×14 6×12
GL4.5-130 2 130-133 8 7×14 6×12
GL4.5-140 2 140-143 8.2 7×14 6×12
GL4.5-150 2 150-153 9 7×14 6×12
GL330-85 2 82-85 3.4 6×14 3×12 GL330
GL335-90 2 90-93 4.6 6×14 7×12 GL335
GL340-105 2 105-108 7.7 8×14 7×13 GL340
GL345
GL345K
GL340-115 2 115-118 8 8×14 7×13
GL340-130 2 130-133 10.5 8×14 8×13
GL350-130 2 130-133 17 7×16 7×14 GL350
GL355
GL355K
GL350-140 2 140-143 18 7×16 7×14
GL350-152 2 152-155 19 6×16 6×14
GL360-152 2 152-155 25 8×16 11×14 GL360
GL360-165 2 165-170 26.5 8×16 11×16
GL360-178 2 178-183 28.6 8×16 11×16
GL360-194 3 194-197 30 9×16 12×16
GL360-203 3 203-206 32 9×16 13×16
GL360-216 3 216-219 35 9×16 13×16
GL360-230 3 230-233 37 12×16 16×16
GL360-254 3 254-257 43 12×16 16×16
GL360-305 3 305-308 57 14×18 26×16
GL380-203 2 203-206 48 8×18 10×16 GL380
GL380-216 3 216-219 50 9×18 13×16
GL380-230 3 230-233 53 9×18 17×16
GL380-254 3 254-257 58 9×18 16×16
GL380-310 3 310-313 71 12×18 15×16
GL380-350 4 350-353 80 16×18 36×16
GL3120-302 3 302-305 176 12×18 ×18 GL3120



Hf Down The Hole DTH Rock Drill Bit


Our Factory

We are a leading manufacturer of drilling tools, like DTH hammers and bits, DTH drill pipes, RC hammers and bits, tophammer button bits, coupling, cross bits, drill rods located in Zhengzhou, Henan, China.

Hf Down The Hole DTH Rock Drill Bit

We have rich experience in this field of DTH hammers and bits for 20 years.We have more than 50 sets of processing equipment to ensure the quality of our product, which has proved worthy by our client's recognition. And these equipments ensure large production capacity and adequate stock.We have all the small models in stock all year long and the bigger ones ready within 15-30 days.

Hf Down The Hole DTH Rock Drill Bit

Owing to high quality, professional serivce and competitive price, we have gotten good reputation from our customers from all over the world, such as France, Spain, Italy, South Africa, Iran, Malaysia, Australia ad etc.

Hf Down The Hole DTH Rock Drill Bit

Our Certificate

Our products has been authorized and certified by TUV and ISO9001: 2008. We guarantee the quality of the machines for one year after the trial run (excluding the wearing parts), but not exceeding 15 months from the date on which machines leave the factory.



Hf Down The Hole DTH Rock Drill Bit
