High Quality Marine Packaged Air Conditioning Plant

High Quality Marine Packaged Air Conditioning Plant photo-1
US$ 1,999 - 2,999 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Cabinet Air Conditioner
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Cabinet Air Conditioner
Place of Origin Guangdong, China
Brand Name HUALI
Model Number MPC~2
Operating Voltage 230 VAC
Mounting Wall / Window Mount
Certification CE
After-sales Service Provided Overseas service center available



 High Quality Marine Packaged Air Conditioning Plant

Description of Marine water chiller

1. Marine water chillers Capacity range: 23.2kw-700KW

2. Hi-efficiency transfer tube has hi-efficiency condensation and anti-corrosion functions.

3. Capacity auto-regulated to ensure the unit work safely under the best working condition and energy-saving state with complete protection devices.

4. Navy or marine water chillers consist mainly of compressor, condenser and dry evaporator etc with features of new design. Easy operation, smooth running and safety. Pressure test, vacuum test and performance test has been conducted on the chillers, It is ready to run after the cooling water and cooling medium pope are connected and power source is on, The chillers form a complete air conditioning system together with other assistance equipment.

Marine water chillers



A.Marine Packaged Air Conditioner

1. Marine Packaged Air Conditioner is the core of marine air conditioner system;

2. Marine Packaged Air Conditioner is intended to regulate the temperature and humidity of ambient air is applied widely to passenger ships,good vessels,navy ships and offshore oil platforms.

3. Marine Packaged Air Conditioner has features of new design,easy operation,smooth running and sately;

4. Pressure test,vacuum test and performance test have beed conducted on the air conditioner.

4. Marine Packaged Air Conditioner is ready to run after the relevant piping is connected and power on.

Parameter of Marine water chiller



Model MPC-2 MPC-3 MPC-3.3 MPC-4 MPC-5 MPC-6 MPC-7 MPC-8 MPC-10 MPC-13 MPC-16
Cooling capac.:KW 23.2 35 38.4 46.4 58 70 81.4 93 116 151 186
Heating Capac.:KW 26.7 39.5 44.2 53.5 67.44 81.4 93 107 134 167 215
Air Flow:m3/h 2180 3710 3710 4240 5010 6310 7160 8200 10500 12350 16100
Outside static pressure:Pa 440 540 540 700 1030 1180 1470 1570 1700 1800 1760
Cooling water flow:m3/h 6 10 10.5 12 15 18 21 24 30 40 50



Photos of Marine water  chiller
