Specifications
1. Leading professional design and manufacture;2. Easy operation and high efficiency;
3. Long servicing life;
4.good price
Kaida wheel loader is very popualr for high quality and best price all over the world. Now we have more than 200 dealer in China mainland. We also have many dealers oversea, such as, Iran, Saudi Arabia, India, the Philippines, Brazil, etc. Please visit our website about more information. We will be looking forward to your kind inquiry.
Specification of Kaida-ZL-18A is listed as following.
1.0 Engine Details
(1) Model: 4100
(2) Engine type: In-line arrangement, water-cooled, one-cycle diesel Engine
(3) Rated Power:44kw
(4) Rated Speed: 2200 r/min (rpm)
2.0 Steering System
(1) Cycloid full hydraulic steering system
(2) System Pressure: 16MPa
3.0 Bucket
(1) Bucket Capacity: 0.7m3
(2) Bucket width: 1600mm
(3) Max. Breakout Force: 48KN
(4) Rated Load: 1000kg
(5) Operating Weight: 1.8T
4.0 Overall Dimensions
(1) Overall Length : 5800mm
(2) Overall Height:2600mm
(3) Overall Width: 1600mm
5.0 Operating Specifications
(1) Drive Means: Four-wheel drive
(2) Min Turning Radius: 4200mm
(3) Driving System: mechanical
(4) Dumping Height: 2900mm
(5) Time of raise:3.0sec.
(6) Hydraulic cycle time: 12.4second.
6.0 Brake System
(1) Service Brake: Four Wheel Hydraulic brake
7.0 Tyre Type:14/90-16
8.0 Wheel base:1750mm
9.0 Wheel Track:1500mm
Shipment: 3 units shipped in 1x40HC.
1.overall weight(kg) | 4000kg | ||||||||||
2.Overall Dimension(mm) | 5300×1910×2830mm | ||||||||||
3.Rated bucket capacity(m3) | 0.8 | ||||||||||
4.Rated load(kg) | 2000kg | ||||||||||
5.dump height (mm) | 3200 | ||||||||||
6.Dump distance | 980 | ||||||||||
7.Max. Tractive Force | 79KN | ||||||||||
10.1Brand and modle | 4102 turbocharged | ||||||||||
11.Type1 | direct injection, horizontal | ||||||||||
12.1Rated power(kw) | 55kw | ||||||||||
13.Rated speed(r/min) | 2200 | ||||||||||
14. Mode | hydraulic torque converter | ||||||||||
15.Max. Speed | 20 km/h | ||||||||||
16.Model of Axle | Hub reduction Axle | ||||||||||
17.Mode | 4-wheel Drive | ||||||||||
Steering system | 18Type23 | Articulated hydraulic steering | |||||||||
19.Max. turning angle | 30±1° | ||||||||||
20Min turning radius(mm) | 5000 | ||||||||||
Tire | 21.Standard tire | 16/70-20 | |||||||||
| Product advantage: | |||||||||||||||
| 1.Streamline design, nice and elegant. | |||||||||||||||
| 2.It uses well-known flat-four engine, which is powerful, reliable, and energy-saving. | |||||||||||||||
| 3. The shovel loader lays flat automatically. It uses computer optimized design with high working efficiency. | |||||||||||||||
| 4.New closed cab, Grammer seat, air condition can be equipped, operating environment is more comfortable. | |||||||||||||||
| 5.It can also add optional items like pallet fort grapple, tube grasp fork, corn fork, rock hopper, bigger peck, snow-push plate, fork and so on, so as to satisfy different demands. | |||||||||||||||
