Fork for Wheel Loader/mini Loader/mini Compact Loader Multifunction

Name: Fork for Wheel Loader/mini Loader/mini Compact Loader Multifunction
Brand: Kaida
SKU: 141576172
Availability: InStock

US$ 5,000 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

Kaida

Model Number:

ZL-918

Shandong Kaida Construction Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Kaida

Model Number ZL-918

Place of Origin Shandong, China

Type Mini Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 5800X1600X2600(mm)

Rated Load 1.8T

Certification ISO9001:2000

Specifications

wheel loader manufacturer
It uses well-known flat-four engine, which is powerful, reliable, and energy

Wheel loader manufacturer

1.overall weight(kg)					3200kg
2.Overall Dimension(mm)					5250×1600×2600mm
3.Rated bucket capacity(m3)					0.7
4.Rated load(kg)					1800kg
5.dump height (mm)					3200 and 3800
6.Dump distance					850
7.Max. Tractive Force					77KN
10.1Brand and modle				4100
11.Type1				direct injection, horizontal water-cooled four-stroke four cylinder
12.1Rated power(kw)				44kw
13.Rated speed(r/min)				2200
14. Mode		hydraulic torque converter
15.Max. Speed		20 km/h
16.Model of Axle			Hub reduction Axle
	17.Mode					4-wheel Drive
Steering system	18Type23					Articulated hydraulic steering
	19.Max. turning angle					30±1°
	20Min turning radius(mm)					4500
Tire	21.Standard tire					14/90-16

Product advantage:
1.Streamline design, nice and elegant.
2.It uses well-known flat-four engine, which is powerful, reliable, and energy-saving.
3. The shovel loader lays flat automatically. It uses computer optimized design with high working efficiency.
4.New closed cab, Grammer seat, air condition can be equipped, operating environment is more comfortable.
5.It can also add optional items like pallet fort grapple, tube grasp fork, corn fork, rock hopper, bigger peck, snow-push plate, fork and so on, so as to satisfy different demands.
