Specifications
Mini Wheel Loader ZL-35 For SaleRated Load Capacity:3T
Rated Bucket Capacity:1.6m3
Max. Dump Height:3200mm
Rated Power:92kw
Engineering & Construction Machinery
Zl-35 Mini Wheel Loader
Technical index:
Rated Load Capacity(T) |
3 |
Rated Bucket Capacity(m3) |
1.6 |
Max. Breakout force (kn) |
112 |
Traction force (kn) |
88.5 |
Wheel track |
2600 |
Max. Dump Height(mm) |
3200 |
Discharging Distance(mm) |
1030 |
Lifting Time (s) |
5.6 |
Lowering Time(s) |
3.4 |
Dumping Time(s) |
1 |
Min. Turning Radius(mm) |
5160 |
Rated Speed(r/min) |
2200 |
Engine Model |
6108 (YTO, China) |
Rated Power(kw) |
92 |
Overall Weight(kg) |
9600 |
Overall Dimension(mm) |
6920×2250×3020 |
1.Using direct injection diesel engine as power, with easy startup and low oil consumption. |
2. Using special drive axle, with strong ability to overcome obstacle. |
|
3. Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space. |
4. It uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality. |
|
5.It uses well-known paint and full-closed cooling system to lower engine and hydraulic system’s temperature efficiently and prolonger the machine’s work life. |
|
6. Widely applying to the construcction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc. |
7. It has single lever operation way, so operation is comfortable and convenient. |
|
9. Widely applying to the construcction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc. |
