Specifications
Cast iron roller1.High hardness 385-415HB
2.High coefficient of friction
3.Better wear resistance and tensity
supply wear-resistant cast iron roller series
cast iron roller / stainless steel roller / stainless mill roll / industrial steel roller / roller core
We are supplying cast iron roller series for casting mill and rolling mill used in metal processing industry. The rolls are made of special cast iron. The roller core material used 42CrMo.
Technical parameters(cast iron roller)
|
Model(cast iron roller)
|
Φ650~700×1400~1650 |
Φ720~850×1650~1850 | |
Φ960~980×1600~2100 | |
Φ1000~1200×1800~2400 |
chemical analysis | |||||||||
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Cu |
Mo |
V |
0.27~0.37 |
0.20~0.40 |
0.20~0.50 |
<0.025 |
<0.025 |
<0.25 |
2.70~3.20 |
<0.25 |
0.9~1.10 |
0.15~0.20 |
Advantages(cast iron roller)
1.Casting and freezing under the effect of centrifugal force, to make the roller has fine configuration, uniform white iron layer, avoid the defects of gas hole, sand explosion and residue, etc.
2. The roller can inlay shaft to shaft sleeve, significantly save on raw material consumption and reduce the weight of roll itself.
3. The work surface hardness of cast iron roll can produce according to users' needs, the outer layer hardness can reach 385-415HB, and has high-performance antiwear, good inner ductility, stable quality.
4. Roll work layer has fine configuration, the hardness change is small, the hardness difference of the whole body of roll is little, thus to ensure the stability of roll quality.
5. Can produce roll in different specifications according to users' requirements, now the largest size can be achieved to 1200*2450.
cast iron roller / stainless steel roller / stainless mill roll / industrial steel roller / roller core
Our services
- Design of installations, Manufacturing of equipment
- Installations, commissioning and training
- One year guarantee except consumptive part
- 24 hours technical support by e-mail
- Calling or door-to-door service
For more information, please feel free to contact me. I am ready to provide you any information about our products that you concern.
TEL: +86 0371 64100199
FAX: +86 0371 64100299
MB: +86 13703951067
Skype: Lezard Zhang
cast iron rollers / stainless steel roller / stainless mill roll / industrial steel roller / roller core
