FC Series Advance Technology Wheat grain dryer
1. What is the wheat grain dryer used for ?
The wheat grain dryer is mainly used for rapeseed,corn, wheat,paddy etc
2. How is wheat grain dryer working ?
Put the wheat grain into the dryer in batch then circulate orderly by the interaction of electric parts and strural par. The hot air from the husk burner gets into the mixed-flow drying layer to across and heat the grain under the action of two electric fans. The air flows and takes off the moisture of the grain. Then the exhaust gas is excluded out of the machine by the exhaust fan when the moisture reaching to the set value, the machine stops working.
3. What is wheat grain dryer advantage ?
a.latest international mixed flow angle plate grain dryer.
b. low temperature, constant temperature, full coverage drying,through the clean heat source of the heat exchange is full covered with no dead angle drying, to ensure food quality.
c. no secondary pollution, stable performance.
d. production capacity increased by 20% than the cross-flow production, reducing moisture rate increased by 20%, damage rate reduced by 1%.
e. inside and outside drying grain moisture is same, make the grain most likely to be preserved for a long time,mildew and damp rate lower more than 90% than the high temperature drying.
4. Wheat grain dryer technical data
Item Type | 5 HXG-102 | 5 HXG-135 | 5 HXG-150 | 5 HXG-300 | |||
Weight(kg) | 2900 | 3000 | 3200 | 7500 | |||
Capacity | Rapeseed | min-max volume(kg) | 7500-10300 | 7500-13450 | 7500-14850 | 12000-30000 | |
Max capacity(kg/h) | 473-1135 | 607-1456 | 675-1620 | 1000-3500 | |||
Corn | min-max volume(kg) | 7500-10450 | 7500-13400 | 7500-16800 | 1200-30000 | ||
Max capacity(kg/h) | 756-1261 | 971-1681 | 1080-1800 | 1000-3400 | |||
Wheat | min-max volume(kg) | 7500-10450 | 7500-13350 | 7500-16800 | 1200-30000 | ||
Max capacity(kg/h) | 315-756 | 405-971 | 450-1080 | 1000-3250 | |||
Paddy | min-max volume(kg) | 6500-8400 | 6500-10850 | 6500-15000 | 9000-27800 | ||
Max capacity(kg/h) | 382-916 | 493-1184 | 548-1315 | 850-2800 | |||
Dimension | Height(mm) | 7330 | 8450 | 9070 | 12180 | ||
Length(mm) | 4228 | ||||||
Width(mm) | 2750 | ||||||
Burner | Max capacity(L/h) | High temperature type:35.5 L/h Low temperature type: 25 L/h | |||||
Heat consumption (KG/ (KG. Water) | Below 5800(below national standard) | ||||||
Fuel | Biomass (branch, rice chaff, straw and so on) coal, oil, gas,natural gas, hot-gas. | ||||||
Power | Conveyor Motor(KW) | 2.25kw(3hp) | |||||
Exhaust air motor(KW) | 3.75kw(5hp) | ||||||
Dirt motor(KW) | 0.25kw(1/3hp) | ||||||
Total | 6.25kw(82/3hp) | ||||||
Performance | Loading time | 47 min | 57 min | 63 min | 69 min | ||
Unloading time | 43 min | 53 min | 58 min | 64 min | |||
Drying rate of commodity grain | Rapeseed/ Wheat/ Paddy | Above 0.6-1.2 | |||||
Corn | Above 1.1-2 | ||||||
Drying rate of seed | Rapeseed | Above 0.2-0.7 | |||||
5. Wheat grain dryer pictures
