Intelligentized Color Sorter for Black Tea, Metak Color Sorter Supplier Price
Metak Color Sorter Application :
Metak CCD Tea color sorter sortex machine price is using the leading CCD technology for sorting all kinds of black tea, green tea etc.
Metak Color Sorter Main parts details :
DSP+FPGA chip
Unique arithmetic of multiple modes combined with color and space ,powful computing capability,ultra-fast date large enough to cope with various operation,a color sorting machine super brain.
Feeding system
Innovative feeding system , ensure that the feeding speed and quantity are uniform, feeding system with innovative winnowing function, automatic winnowing for ethereal substances and dust on materials,which can effectively enhance the accuracy of color sorting.
Touch Screen
Touch Screen professional manufactureers with the touch screen,the affinity of the man-machine interface,sticking out a mile's operation menu,simple settings,so that customers can quickly master the color sorting machine a variety of performace.
Wide Chute
320MM wide chute international generic application,special anodizing process,production while ensuring our products to international standard.
CCD carmeras
Imported high-end 2048 pixels CCD Carmeras equipped with well-know international top brand,Can identify these tiny spots 0.04mm.More scientific and rational combination of optimized optical desigh of international algortthms to identify more clearly yellow,idenfify regional brodaer,more accurate color selection.
Ejectors
Intellectual property rights and the development of color sorter dedicated solenoid valve; special high-strength materials, strong suction, no residual magnetism, linear gas against precision, high consistency, significantly lower than the band; frequency of 1200Hz per second or more, and most fast response time of 0.6ms; the life of 50-100 million times.
Intelligent functional design air curtain
Through the fan blowing system, resulting in high-speed airflow lens front glass dust, ethereal, etc. quickly remove to ensure that the resolution and color sorting accuracy.
| Model | TCSV3 | TCSV4 |
| Type | V- Structuer Three-layers | V- Structuer Four-layers |
| Chute | 6 | 6 |
| Channels | 384 | 384 |
| Output (Kg/h) | <600 | <800 |
| Carryover(bad/good) | ≥ 5:1 | ≥5:1 |
| Accuracy (%) | ≥99% | ≥99% |
| Voltage | 380V50Hz | 380V50Hz |
| Power(kw) | 5.5-6.5 | 6.8-8.6 |
| Air Pressure(Mpa) | 0.6-0.8 | 0.6-0.8 |
| Air Consumption(L/min) | <5000 | <5400 |
| Weight(kg) | 2650 | 3286 |
| Dimension(L*W*Hmm) | 2676*2530*2950 | 2676*2530*3432 |
Remarks: The parameters are based on impurity 3% of Green tea, actual output changes according to the impurity of raw material. If products update ,no further notice. Please reference to the machine.
1. Inner packing is vacuum-packed with aluminum foil.
2. Outer packing is fumigation-free wood packages.
3. Suit for long sea voyage.
4. Sea Transportaion and Air Transportation are available.
Metak Color Sorter Payment Terms:
1. Delivery time: Based on the customer requirement, 15-20 working days;
2. Shipping: By sea with polywood case.
3. Payment Terms: 30% balance, 70% before shipment by TT, or Letter of Credit.
After-sale Services-----
1. A strong central technical team in Hefei, China: Ready for supporting local agent or wholesales with training, advice and technical support.
2. One year full warranty (except for consumable parts) and a lifelong warranty on the machine structure upon the date of purchase.
3. Service line is available for emergency support: telephone, email, video or on site solutions by our technical experts.
4. Serviced and Supported wherever customers are located.
5. Free software update.
