Automatic Ultrasonic Medical Washer

Automatic Ultrasonic Medical Washer

Automatic Ultrasonic Medical Washer Introduction

It is suitable for instruments including scalpel, forceps, hemostatic forceps, dressing change bowl, waist disk, and all kinds of glassware to be washed. It is widely used in operation room, supply room, CSSD and so on.

Automatic Ultrasonic Medical Washer Technology Advantage

1.Ultrasonic cleaning slot not only can be single used ,but also can be equipped with extension slot,with PID accurate temperature control ,which is convenient to clean various instruments in order to reach the best cleaning effect.

2.It adopts high quality stainless steel design and surface treated by electrolysis. Each connection adopts a circular-arc connection mode, which avoids residueis retention, is easy to clean and has an elegant appearance. Heat insulation materials with good performance are pasted on outer surface of the slot, which can reduce the consumption of heat and slow down noise.

3.Gas spring of switching gate within the instrument can slow down the speed of switching gate, prevent operator from clamping injury, relieve the tension of witching gate and be convenient to operate.

4.Shower slot: It not only can be connected with ultrasonic cleaning machine to become connecting body slot, but also can be single used. It adopts strength circulating pump and special nozzle to spray, clean and flush instruments treated by ultrasonic pre-and postmany times under the function of circulating pump .The function of boiling disinfection and oiling are equipped with.

5.Dry slot: It not only can be single used, but also can be associated with other two slots. It adopts high quality effective air filter, heater and imported effective fan, which can dry goods after cleaning and disinfection.

6.The three slots above adopt PLC and touch screen, which have an accurate stable control and friendly man-machine interface.

7.Core components including circulating pump, solenoid valve,oiling pump, electric adopt international brand products, which improve the stability of instruments greatly.

Automatic Ultrasonic Medical Washer Safety Feature

Protection of heating with water shortage and ultrasonic: When water level in slot is lower than setting water level due to some reasons, the device can’t begin to heat and ultrasonic work, which can prevent the device from running with water shortage, having damage to device and cleaning goods.

Over temperature protection of heating tube: It cuts off power to make sure that the device can run safely when the heating tube caused by some reason is on overheating.

Safety protection of electric power: The design with short circuit and leakage protection function make sure of safety of device and operator.

Automatic Ultrasonic Medical Washer Main Parameter

Ultrasonic frequency: 40KHZ (single frequency),40/80KHz(double frequency), 40/80/120KHz(three frequency)(selected)

Capacity: 80L

Heating mode: electric heating

Heating power of ultrasonic cleaning slot: 5400W

Ultrasonic power of ultrasonic cleaning slot:1200W

Heating power of shower slot : 5400W

Washing power of shower slot: 750W

Heating power of drying slot: 3000W

Fan power of drying fan: 3350W
