2000 Liters Class B Double Door Autoclave Sterilizer

2000 Liters Class B Double Door Autoclave Sterilizer

Model:

HA-BVD2000

Volume:

2000 liters

Inner Chamber Dimension(L*W*H mm):

1600*900*1400

Overall Dimension (L*W*H mm):

1950*1750*2200

Voltage/Power:

4.5KW

Net Weight:

2500Kgs

Optional: 250L, 360L, 600L, 800L, 1200L, 1500L, 2500L, 3000L

Product Features and Function:

1. Main body is with hrizontal rectangle double layer structure, inside chamber is SUS30408 or SUS31608 high quality stainless steel, outer layer is brushed decorative sheet.

2. Control System: Siemens PLC and Siemens touch screen.

3. Piping System: Germany Burkert or GEMU pneumatic angle type value, water ring vacuum pump, 0.22um high efficiency sterile medical grade filters.

4. The pipe clamp adopts the quick connectors, the piping and the related spares are all according to the sanitation standard.

The Software Features:

1. With Germany Simens PLC platform independent research and development, human-Machine Interaction, convenient for operation.

2. Software design and manufacture products in strict accordance with the technical requirements for the sterilization process.

3. The Operating authority is divided into three levels to the manager, the technologist, and the operators.

4. Program interlocked, by the program is running, the sealing door can not be open.

5. All the alarm and the technical figures can be recorded and print.

6. If the inner chamber is higher than the safety pressure, the door can not be open.

7. Perfect product safety protection measures, 4 level emergency treatment of abnormal state.

Product Usage:

Widely used in pharmaceutical, medical, scientific and other industries for the high temperature sterilization, cooling and drying process to the biological products,medical devices, sterile clothing, tools utensils, media and the other items.

Spare Parts/Accessories:

With an external Air Compressor.

Optional:

Single Door Type

External Steam Generator
