Full Stainless Steel Type Horizontal Autoclave Sterilizer

Full Stainless Steel Type Horizontal Autoclave Sterilizer photo-1
Full Stainless Steel Type Horizontal Autoclave Sterilizer photo-2
Full Stainless Steel Type Horizontal Autoclave Sterilizer photo-3
Full Stainless Steel Type Horizontal Autoclave Sterilizer photo-4
US$ 4,959.23 - 10,310.43 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Pressure Steam Sterilization Equipments
Brand Name:
Bluestone Autoclave
Model Number:
HA-BD
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Nanjing Ningbo Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Type Pressure Steam Sterilization Equipments
Brand Name Bluestone Autoclave
Model Number HA-BD
Place of Origin Anhui, China

Specifications

Horizontal Autoclave Sterilizer
For Hospital Use
150L 200L 280L
Full Stainless Steel Material
MOQ 1 SET

Bothe Inside And Outside With Stainless Steel Material  Horizontal Autoclave Sterilizer



Specification of Horizontal Autoclave Sterilizer :

ModelHA-BD150HA-BD200HA-BD280
Volume150 Liters200 Liters280 Liters

Sterilizing

Chamber Volume

Ø440*H1000 mmØ515*H1000 mmØ600*H1000 mm

Working

Pressure

0.22 Mpa0.22 Mpa0.22 Mpa

Max Working

Pressure

0.23 Mpa0.23 Mpa0.23 Mpa

Working

Temperature

134°C134°C134°C
Adjustment of Temperature105°C-134°C105°C-134°C105°C-134°C

Adjustment

time of Sterilization

0-60 Minutes0-60 Minutes0-60 Minutes

Adjustment

time of Dry

0-60 Minutes0-60 Minutes0-60 Minutes
Heat Average≤± 1°C≤± 1°C≤± 1°C
Power

9 KW /

AC380V 50Hz

9 KW /

AC220V 50Hz

12 KW /

AC380V 50Hz

Product

Dimension(mm)

1400*600*13001400*670*16501400*770*1780

Package

Dimension (mm)

1550*750*18501560*820*18501680*920*2100

Gross Weight/

Net Weight

320 kg /240 kg350 kg /260 kg465 kg / 365 kg



Feature of Horizontal Autoclave Sterilizer:

Outsied and Inside are full stainless steel material.

1. The steam can't go through to chamber when the door haven't close, and the pilot off inform. You can processing dry operate.
2. When the pressure inner over 0, 027MPa. The door be locked and can't be open.
3. If you not choose the sterile time and star the machine, buzzer sound.
4. If you mistake open the door in the course of start, the jacker value auto off and open the chamber value.
5. Lack water the pilot on, heating and sterile pilot off, the buzzer sound and auto release steam.
6. Overload and leakage protection, when leakage or over current occur, it auto off the power.
7. Temperature controlled not work and the inner pressure over 0.165MPa, the safety value auto open.

Main Functions:
1. With drying function, suitable dressing drying.
2. With over-temperature, over-pressure auto-protection device.
3. The power will be cut off automatically, and cut-off water and alarm when the machine lack water.



Product Show of China Horizontal Autoclave Machine:

Full Stainless Steel Type Horizontal Autoclave SterilizerFull Stainless Steel Type Horizontal Autoclave Sterilizer



Welcome to contact us to get more details and discount!
