Specifications
Horizontal Autoclave SterilizerFor Hospital Use
150L 200L 280L
Full Stainless Steel Material
MOQ 1 SET
Bothe Inside And Outside With Stainless Steel Material Horizontal Autoclave Sterilizer
Specification of Horizontal Autoclave Sterilizer :
| Model | HA-BD150 | HA-BD200 | HA-BD280 |
| Volume | 150 Liters | 200 Liters | 280 Liters |
Sterilizing Chamber Volume | Ø440*H1000 mm | Ø515*H1000 mm | Ø600*H1000 mm |
Working Pressure | 0.22 Mpa | 0.22 Mpa | 0.22 Mpa |
Max Working Pressure | 0.23 Mpa | 0.23 Mpa | 0.23 Mpa |
Working Temperature | 134°C | 134°C | 134°C |
| Adjustment of Temperature | 105°C-134°C | 105°C-134°C | 105°C-134°C |
Adjustment time of Sterilization | 0-60 Minutes | 0-60 Minutes | 0-60 Minutes |
Adjustment time of Dry | 0-60 Minutes | 0-60 Minutes | 0-60 Minutes |
| Heat Average | ≤± 1°C | ≤± 1°C | ≤± 1°C |
| Power | 9 KW / AC380V 50Hz | 9 KW / AC220V 50Hz | 12 KW / AC380V 50Hz |
Product Dimension(mm) | 1400*600*1300 | 1400*670*1650 | 1400*770*1780 |
Package Dimension (mm) | 1550*750*1850 | 1560*820*1850 | 1680*920*2100 |
Gross Weight/ Net Weight | 320 kg /240 kg | 350 kg /260 kg | 465 kg / 365 kg |
Feature of Horizontal Autoclave Sterilizer:
Outsied and Inside are full stainless steel material.
1. The steam can't go through to chamber when the door haven't close, and the pilot off inform. You can processing dry operate.
2. When the pressure inner over 0, 027MPa. The door be locked and can't be open.
3. If you not choose the sterile time and star the machine, buzzer sound.
4. If you mistake open the door in the course of start, the jacker value auto off and open the chamber value.
5. Lack water the pilot on, heating and sterile pilot off, the buzzer sound and auto release steam.
6. Overload and leakage protection, when leakage or over current occur, it auto off the power.
7. Temperature controlled not work and the inner pressure over 0.165MPa, the safety value auto open.
Main Functions:
1. With drying function, suitable dressing drying.
2. With over-temperature, over-pressure auto-protection device.
3. The power will be cut off automatically, and cut-off water and alarm when the machine lack water.
Product Show of China Horizontal Autoclave Machine:
Welcome to contact us to get more details and discount!
