Specifications
1.Toshiba brand CCD sensor2.Super wide chute to achieve high output and precision
3.SMC Solenoid Valve
4.LED light
Self-checking Security System Kernel Color Sorter with Aluminum Solenoid Valve Device
1.Each machine has two filers, one filters oil impurities,and the other filters water fog impurities to let the pure,dry compressed air into the spray valve,so the filter has a longer life.
2.Specially design technology, our injector can move up or down, move left to right side by adjust the screw. injector will be aged after many years work, so the air from the injector will be weak.You can adjust the injector position to a ideal position to ensure the strong and enough air and sorting accuracy.It can prolong the injector lifetime.
3.The sorter is able to provide double-side detection and has various working modes to meet requirements of various materials thus has common applicability, high sorting precision and low carryover rate.
Model |
JTDM-CCD3R |
JTDM-CCD4R |
JTDM-CCD5R |
JTDM-CCD6R |
Output (Ton/hr) |
4-7 |
5-11 |
7-12 |
10-15 |
Channels (big/small) |
64/192 |
64/256 |
64/320 |
64/384 |
Ejectors |
192 |
256 |
320 |
384 |
Light source |
LED light |
LED light |
LED light |
LED light |
Pixel of camera |
5000*3 |
5000*3 |
5000*3 |
5000*3 |
Color sorting accuracy |
>99.99% |
>99.99% |
>99.99% |
>99.99% |
Carryover rate |
>10:1 |
>10:1 |
>10:1 |
>10:1 |
Host power |
1.0-2.5 |
1.2-3.0 |
1.4-3.5 |
1.6-4.0 |
Air pressure |
≥0.6Mpa |
≥0.6Mpa |
≥0.6Mpa |
≥0.6Mpa |
Air consumption (L/min) |
1000-1800 |
1200-2500 |
1500-3000 |
1800-3600 |
Power supply |
220V/50HZ |
220V/50HZ |
220V/50HZ |
220V/50HZ |
Machine weight (kg) |
900 |
1100 |
1300 |
1500 |
Package |
wooden case |
wooden case |
wooden case |
wooden case |
