GNSS Survey Antenna CORS Antenna HX-GS282A
- 1000 Unit / Units per Month
- Xingang TJ
- T/T L/C D/P D/A
-
Sand Water Filter/Water treatment plants
-
Automatic Doypack Seal Machine (insert and sealing machine)
-
IPX3/IPX4 Hand-held Water Spray Nozzle Test Device IEC 60529
-
IPX5,IPX6 Jet Nozzle of IEC 60529， Brass material
-
Adjustable and multifunctional Spring Impact Hammer IK01-IK07 Level Tester
-
Test probe 43 IEC 61032-Probe 43-Figure 17 Jusdtest
Product Details
| Place of Origin: | Tianjin, China | Brand Name: | SunNav | Model Number: | HX-GS282A, HX-GS282A |
Product Description
GNSS Survey Antenna CORS Antenna HX-GS282A
Specifications of GNSS Survey Antenna CORS Antenna HX-GS282A
Antenna Specification | Frequency Range: GPS L1, GLONASS L1, SBAS |
| Impedance: 50 Ohm | |
| Polarization: RHCP | |
| Axial Ratio: ≤ 3 dB | |
| Azimuth Coverage: 360° | |
| Output VSWR: ≤ 2.0 | |
| Gain at Zenith: ≥ 5.5 dBi | |
| Phase Center Error: ± 2 mm | |
LNA Specification | LNA Gain: 40 dB |
| Noise Figure: ≤ 2.0 dB | |
| Output VSWR: ≤ 2.0 | |
| Ripple: ± 2dB | |
| Drain Voltage: 3--18 VDC | |
| Current Consumption: ≤ 45 mA | |
| Group Delay: ≤ 5 ns | |
Mechanical Specification | Dimension: φ147 x 61.8 mm |
| Connector: TNC Female | |
| Weight: 400g | |
Environmental Specification | Operating Temperature: -40°C to +85°C |
| Storage Temperature: -55°C to +85°C | |
| Humidity: 95% Non-Condensing | |
GPS Antenna HX-GS282A | |
1. Using multi feed point design to ensure the superposition of phase center and geometrical center which
could minimize the influence of measurement error to lowest range
2. High gain of the antenna element and the direction map beam width to make sure the receiving satellites
performance of low elevation mask
3. Resistance multipath effects board inside could reduce the measurement error caused by multipath
4. Water proof, shock proof and lightning resistance
Survey antenna is the traditional RTK product standard antenna,can be widely used in land survey,marine
survey,channel survey,seismic monitoring,bridge survey,container opertion,etc.
According to the size, volume of products,using standard packaging.
Via international express (DHL, Fedex, UPS, TNT)are all available.It can be fast for you to transport the goods in your hands.
SunNav Technology Co., Ltd. is a high-tech enterprise that specializes in researching and manufacturing high-precision GNSS motherboard and industrial GNSS products.
Our aim is to provide the high-quality and high-security GNSS products and services.
We have an experienced core technology R&D team, who has been unremitting efforts to research and develop the new GPS and GNSS technologies.
