Home > Products > New Products > MTS800B Total Station sunnav
MTS800B Total Station sunnav
- 100 Piece / Pieces per Month
- Tianjin
- Credit Card PayPal
Product Details
| Place of Origin: | Tianjin, China | Brand Name: | sunnav | Model Number: | MTS800B |
Product Description
MTS800B Total Station
MODEL | MTS800B Series | |
Telescope |
| |
Clear objective aperture | 45mm | |
Magnification | 30X | |
Image | Erect | |
Angle of field of view | 1º30’ | |
Shortest stadia | 1.5m | |
Method of measurement | Absolutely code | |
Method of Detecting | Horizontal:Double | |
|
| |
Accuracy | 2” | |
Display panel | Double face | |
Distance Measurement |
| |
Reflector-less | Accuracy | 5mm+3ppm |
Measuring range | 350m | |
Reflector | Accuracy | 3mm+2ppm |
Measuring range | 5000M | |
Compensator |
| |
Range | ±3’ | |
Output Interface |
| |
Communication standard | RS232C | |
EDM Interface | yes | |
Memory points | 50000 Points | |
Power |
| |
Battery | Rechargeable Ni-HM battery | |
Working time | About 8 hours | |
Working temperature | -20℃~+50℃ | |
Waterproof | IP54 | |
Net weight | 5.8kg | |
According to the size, volume of products,using standard packaging.
Via international express (DHL, Fedex, UPS, TNT)are all available.It can be fast for you to transport the goods in your hands.
SunNav Technology Co., Ltd. is a high-tech enterprise that specializes in researching and manufacturing high-precision GNSS motherboard and industrial GNSS products.
Our aim is to provide the high-quality and high-security GNSS products and services.
We have an experienced core technology R&D team, who has been unremitting efforts to research and develop the new GPS and GNSS technologies.
