Home > Manufacturing & Processing Machinery > Machinery for Garment, Shoes & Accessories > Sewing Machine > 1-341 1-needle Cylinder Bed Walking Foot and Needle Feed Large Vertical Rotary Hook, Industrial Sewing Machine
1-341 1-needle Cylinder Bed Walking Foot and Needle Feed Large Vertical Rotary Hook, Industrial Sewing Machine
US$ 1 - 2
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Industrial Sewing Machine
Place of Origin:
Shaanxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China main seaport or air port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Keestar GA5-1 Heavy Duty Sewing MachineUS$ 1 - 2MOQ: 1 Set -
205-420 Cylinder-bed Semi Long Arm Walking Foot Needle Feed Large Shuttle Hook Extra Heavy-duty Upholster Sewing MachineNegotiableMOQ: 1 Set
-
Keestar 411N Cylinder Bed Single Needle Drop Feed Super-long Arm Heavy-duty Transverse Stitching Upholstery Sewing MachineNegotiableMOQ: 1 Set
-
1-341 1-needle Cylinder Bed Walking Foot and Needle Feed Large Vertical Rotary Hook Upholstery Sewing MachineUS$ 1 - 2MOQ: 1 Set
-
411N Single Needle Cylinder Arm Heavy Duty Industrial Leather Sewing MachineNegotiableMOQ: 1 Set
Condition
New
Type
Industrial Sewing Machine
Place of Origin
Shaanxi, China
Brand Name
Keestar
Model Number
1-341
Stitch Formation
Lock Stitch
Mechanical Configuration
Cylinder-Bed
Max. Sewing Speed
2,000spm
Max. Sewing Thickness
10mm
Stitch Length
max.10mm
Power
550W/750W
Feed Mechanism
Multiple
Certification
ISO9001
After-sales Service Provided
Overseas third-party support available
1-341 1-needle cylinder bed walking foot and needle feed large vertical rotary hook industrial sewing machine
Application:
Keestar 1-341 1-needle, cylinder bed, walking foot and needle feed, large vertical rotary hook, industrial sewing machine sewing medium and heavy weigh materials such as textile, leather, vinyl and various synthetics
fabrics, etc.
Suitable for sewing such arc and curved products as cushion, boots, bag, luggage bag, handbag, etc
Features:
- Single needle, slide thread take-up lever
- Cylinder bed diameter 72mm suitable for sewing curved and cylindrical products
- Vertical large hook improves the working efficiency
- Compound feed assures the good sewing results even stitching medium and uneven materials
- Clipper-built needle plate assures the smooth sewing for small articles
- High presser foot lift height assures smooth placement/removal of extra heavy weight materials.
- Built-in upper feed mechanism prevents oil from being splashed
Specification:
| Model | 1-341 | ||||
| Stitch length | max. 10mm | ||||
| Max. sewing speed | 2,000spm | ||||
| Stitch type | Lockstitch | ||||
| Feed mechanism | walking foot and needle foot | ||||
| Needle bar stroke | 33.36mm | ||||
| Presser foot lift | By hand | 8.5mm | |||
| By knee | 16mm | ||||
| Needle size | DD×17 14#-24# | ||||
| Cylinder dia. | 72mm | ||||
| Alternating presser foot lift | 2-5mm(standard 3.2mm) | ||||
| Working space | 225×110mm | ||||
| Lubrication | manual | ||||
