Home > Packaging & Printing > Packing Machinery > Coding Machine > YS-380FW Ink Wheel Code Printer Ink Marking Machine
YS-380FW Ink Wheel Code Printer Ink Marking Machine
US$ 1 - 382
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Application:
Packaging
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Date Printer/Plastic Bottle Coding MachineUS$ 1 - 262MOQ: 1 Set -
Electric Ribbon Coding Printer HP-241BUS$ 1 - 219MOQ: 1 Set
-
Printing Roll for Date Printer YS-cp003US$ 1 - 7MOQ: 5 Sets
-
Wider YS-380FW Ink Wheel Code Printer Ink Marking Machine Date Coding PrinterUS$ 1 - 382MOQ: 1 Set
-
Date Printer Glass Bottle or Plastic Bottle Coding MachineUS$ 1 - 262MOQ: 1 Set
Condition
New
Automatic Grade
Automatic
Application
Packaging
Place of Origin
Guangdong, China
Brand Name
YASON
Model Number
YS-380FW
Packaging Material
Paper
Packaging Type
Cartons
Driven Type
Electric
Voltage
220V 50Hz
Power
18W
Dimension(L*W*H)
440 * 465 * 280 mm
Weight
30kg
Certification
NULL
After-sales Service Provided
No overseas service provided
Name:Wider YS-380FW ink wheel code printer ink marking machine date coding printer
Technical parameters:
Power supply voltage: 220V 50Hz
Power: 18W
Solid ink wheel size: 35 * 15MM (two combined)
Print speed: up to 300 beats / min
Minimum to be printed: Length 50 mm * Width 30 mm
Maximum printed material: length 500 mm * Width 340 mm
Max Printing lines: 10 lines, up to 11 characters per line
Imprint location: Unilateral be adjusted within 60-250 mm
Font Size: Width 2 mm * Height 3 mm (entity words)
Dimensions: 440 * 465 * 280 mm
Weight: 26kg
Note: the max width this machine can make is 340 mm
Device Name: Solid ink marking machine
Equipment Model: YS-380FW (wide type, stainless steel)
Equipment Introduction:
Marking machine, also known as rapid ink wheel code printer, use a separate machine, mainly used for paper bags, paper labels, plastic bags, plastic labels and printed on thin paper production date, batch number and other identification. With automatic sub-sheets, automatic counting, automatic positioning and high-speed coding features. This machine adopts advanced solid ink, with instant printing and instant dry, easy to erase the excellent performance, especially for paper, plastic film, aluminum foil bags and other non-absorbent materials and paper packaging production date code.
Equipment Features:
1.Solid ink coder is an advanced contact-type thermal coder. The machine automatically intermittent heating and precision mechanical combination, according to user needs, choose a code content and coding position, and set the number of sheets of play yards play yards fast, reliable, clear writing, playing action code and count using photoelectric switch control.
2.The aircraft structure, stainless steel structure, photoelectric control, automatic counting, and the preset number and location of charge sheets.
3.The use of advanced solid ink printing, writing clear, instant printing and instant dry, easy to erase.
4.The ink marking machine is widely used in medicine, food, cosmetics, hardware and other labels, plastic bags, date, batch number, expiration date printed a variety of industries such as flexible packaging cartons, paper, plastic bags, aluminum foil and other materials surface coding.
The following is the video about this machine :
